Free connection of digital signals
Free configuration of digital outputs
10
Function library
10.13
10.13.2
L
10.13-10
EDS82EV903-1.0-11/2002
l
C0415/2 ð 15: The status message ”CCW rotation” is the signal source for
X3/A1
l C0415/1 ð 60: The status of bit 1 of the process data word CAN-IN1/word
is the signal source for K1
)
))
) Note!
The process data input words CAN-IN1.W1/FIF-IN.W1,
CAN-IN1.W2/FIF-IN.W2, CAN-IN2.W1 and CAN-IN2.W2 can be
defined as analog word or digital word (16 bit). If you link digital
outputs (C0415/x = 60 ... 135), they must be defined as digital
input words. Otherwise the output signal would be incorrect.
Pleaseconsiderthe waythe signals aremapped with the current threshold C0156
when monitoring a V-belt (monitoring signals 20, 21, 22):
l The display value (C0054) is smoothened with a ring memory with 500 ms.
l The value set under C0156 corresponds to a percentage of the rated
controller current I
r
.
l If you use the control mode “V/f characteristic control with square
characteristic” (C0014 = 3) C0156 will be internally adapted via the output
frequency:
C0156
int
[%] = C0156 [%] ⋅
f
2
[Hz
2
]
C0011
2
[Hz
2
]
Examples
Signal level for V-belt monitoring
