Free connection of digital signals
Free configuration of digital process data output words
10
Function library
10.13
10.13.3
L
10.13-14
EDS82EV903-1.0-11/2002
l
C0417/4 ð 16: The status message “Ready for operation” is the signal
source for bit 3.
l C0418/5 ð 101: Bit 2 of CAN-IN2.W1 is the signal source for bit 4.
)
))
) Note!
The process data output words CAN-OUT1.W1/FIF-OUT.W1,
CAN-OUT2.W1 and FIF-OUT.W2 can also be assigned as analog
word under C0421:
l If digitally configured under C0417 or C0418 not simultaneous
analog assignment with C0421 (C0421/x = 255)!
l With analog configuration under C0421 no simultaneous digital
assignment with C0417 and C0418 (C0417/x = 255, C0418/x =
255)!
l Otherwise the status information would be incorrect.
