Lenze E82EV752K4C

Code table
10
Function library
10.20
L
10.20-12
EDS82EV903-1.0-11/2002
Code IMPORTANTPossible settings
No. SelectionLenzeName
C0101
(A)
Main setpoint
acceleration times
^ 10.7-1
1 C0012 5.00 0.00 {0.02 s} 1300.00
Binary coding of the digital signal sources
C
/
C
/
2 T
ir
1 2.50
y
g
g
g
assigned under C0410/27 and C0410/28
d
e
t
e
r
m
i
n
e
s
a
c
t
i
v
e
t
i
m
e
p
a
i
r
3 T
ir
2 0.50
determines active time pair
4 T
ir
3 10.00
C0103
(A)
Main setpoint
deceleration times
C0410/27 C0410/28
LOW LOW
active
C0012; C0013
1 C0013 5.00 0.00 {0.02 s} 1300.00
HIGH LOW
L
O
W
H
I
G
H
;
T
ir
1; T
if
1
T
2
T
2
2 T
if
1 2.50
LOW HIGH
H
I
G
H
H
I
G
H
T
ir
2; T
if
2
T
i
3
;
T
i
f
3
3 T
if
2 0.50
HI
G
HHI
G
H T
ir
3; T
if
3
4 T
if
3 10.00
C0105 Deceleration time
quick stop (QSP)
5.00 0.00 {0.02 s} 1300.00 • Quick stop (QSP) decelerates the drive
to standst ill according to the ramp set
under C0105.
• If the output frequency falls below the
threshold C0019, the DC-injection brake
(DCB) will be activated.
• The S-shaped ramp (C0182) has a lso an
effect on quick stop!
– Reduce the time setting under C0105
to reach the desired deceleration
time for quick stop.
– The S-shaped ramp for the quick stop
can be switched off under C0311 (as
of software 3.1).
^ 10.7-4
C0106 Holding time for
automatic
DC-injection brake
(Auto DCB)
0.50 0.00
= auto DCB not active
{0.01 s} 999.00
=
∞
Holding time, if DC-injection brake is
activated because the value falls below t he
setting under C0019.
^ 10.7-6
C0107 Holding time DC
injection brake
(DCB)
999.00 1.00 {0.01 s} 999.00
=
∞
Holding time, if DC-injection brakes are
activated via an external terminal or control
word.
^ 10.7-6
C0108* Gain analog output
X3/62
(AOUT1-GAIN)
128 0 {1} 255 Standard I/O: C0108 a nd C0420 ar e the
same
Application I/O: C0108 and C0420/1 are the
same
^ 10.12-4
C0109* Offset analog
output X3/62
(AOUT1-OFFSET)
0.00 -10.00 {0.01 V} 10.00 S t a ndard I/O: C0109 and C0422 are the
same
Application I/O: C0109 and C0422/1 are the
same
^ 10.12-4
