Code table
10
Function library
10.20
L
10.20-15
EDS82EV903-1.0-11/2002
Code IMPORTANTPossible settings
No. SelectionLenzeName
C0127
v
Setpoint selection 0
0 Absolute setpoint selection in Hz via C0046 or
process data channel
1 Setpoint selection normalised via C0141 (0... 100
%) or process data channel (
±16384 = C0011)
C0128 Service code Modifications only by Lenze Service!
C0135
*
Controller control
word (parameter
channel)
Bit Assignment
• Control via parameter channel. The most
important control commands are
grouped as bit commands.
• C0135 cannot be change d using the
keypad
1|0 JOG1, JOG2, JOG3 or C0046 (NSET1-JOG1/3,
NSET1-JOG2/3)
00
01
10
11
C0046 active
JOG1 (C0037) active
JOG2 (C0038) active
JOG3 (C0039) active
2
0
1
Current direction of rotation (DCTRL1-CW/CCW)
not inverted
inverted
3
0
1
Quick stop (DCTRL1-QSP)
not active
active
4
0
1
Stop ramp function generator
(NSET1-RFG1-STOP)
not active
active
5
0
1
Ramp function generator input = 0
(NSET1-RFG1-0)
not active
active (decelerat io n to C0013)
RFG1 = Ramp function generator main
setpoint
6
0
1
UP function motor potentiometer (MPOT1-UP)
not active
active
7
0
1
DOWN function motor potentiometer
(MPOT1-DOWN)
not active
active
8 Reserved
9
0
1
Controller inhibit (DCTRL1-CINH)
Controller enabled
Controller inhibited
10 TRIP set (DCTRL1-TRIP-SET) Sets ”external error” in the controller
(
EEr, LECOM No. 91)
11
0
Þ 1
TRIP reset (DCTRL1-TRIP-RESET)
Edge causes TRIP reset
13|12 Parameter set changeover (DCTRL1-PAR2/4,
DCTRL1-PAR3/4)
00
01
10
11
PAR1
PAR2
PAR3
PAR4
14
0
1
DC injection brake (MTCRL1-DCB)
not active
active
15 Reserved
