Code table
10
Function library
10.20
L
10.20-20
EDS82EV903-1.0-11/2002
Code IMPORTANTPossible settings
No. SelectionLenzeName
C0200* Software ID
number
Only PC display
x = Main version, y = Subversion
82S8212V_xy000 8200 vector 0.25 ... 11 kW
82S8212V_xy010 8200 vector 15 ... 90 kW
C0201* Software
generation date
Only PC display
C0202*
Software ID
Output to keypad as string in 4 parts à 4 characters Only keypad display
1
number
82S8
2 212V
3 _xy0 x = Main version, y = Subversion
4 zz 00 = 8200 vector 0.25 ... 11 kW
10 = 8200 vector 15 ... 90 kW
C0220* Acceleration time -
additional setpoint
(PCTRL1-NADD)
5.00 0.00 {0.02 s} 1300.00 Main setpoint ð C0012
^ 10.7-1
C0221* Deceleration time -
additional setpoint
(PCTRL1-NADD)
5.00 0.00 {0.02 s} 1300.00 Main setpoint ð C0013
C0225
(A)
Acceleration time -
process controller
setpoint
(PCTRL1-SET1)
0.00 0.00 {0.02 s} 1300.00
Acceleration encoder for process controller
setpoint = PCTRL1-RFG2
C0226
(A)
Deceleration time -
process controller
setpoint
(PCTRL1-SET1)
0.00 0.00 {0.02 s} 1300.00
C0228
(A)
Unhide time -
process controller
0.000 0.000 {0.001 s} 32.000 0.000 = Process controller output is
transferred without unhiding
C0229
(A)
Hide time - process
controller
0.000 0.000 {0.001 s} 32.000 0.000 = “Fading-off” switched off (C0241)
C0230
(A)
Min. limit process
controller output
-100.0 -200.0 {0.1 %} 200.0
Asymmetric limit of process controller
output re f . to C0011
• If value f alls below C0230 or exceeds
C
0
2
3
1
:
C0231
(A)
Max. limit process
controller output
100.0 -200.0 {0.1 %} 200.0
C
0
2
3
1
:
– Output signal PCTRL1-LIM = HIGH
after time s et under C0233
• Set C0231 > C0230
C0232
(A)
Offset inverse
characteristic
process controller
0.00 -200.0 {0.1 %} 200.0 Ref. to C0011
C0233*
(A)
Delay
PCTRL1-LIM=HIGH
0.000 0.000 {0.001 s} 65.000 ”Debouncing” of digital output signal
PCTRL1-LIM (limit for process controller
output exceeded)
• Sets PCTRL1-LIM = HIGH if the
following still applies after time set:
– Val ue below C0230 or higher than
C0231
• Transition HIGH ð LOW without delay
C0234*
(A)
Delay
PCTRL1-SET=ACT
0.000 0.000 {0.001 s} 65.000 ”Debouncing” of digital output signal
PCTRL1-SET=ACT (process controller
setpoint = process controller actual value)
• Sets PCTRL1-SET=ACT = HIGH if the
following still applies after time set:
– Difference between PCTRL1-SET and
PCTRL1-ACT is below threshold under
C0235
• Transition HIGH ð LOW without delay
