General data/application conditions
4
Technical data
4.2
L
4.2-4
EDS82EV903-1.0-11/2002
Analog inputs
Analog outputs
With standard I/O
1 input, optionally bipolar
W
i
t
h
s
t
a
n
d
a
r
d
I
/
O
1 output
With application I/O
2 inputs, optionally bipolar
W
i
t
h
a
p
p
l
i
c
a
t
i
o
n
I
/
O
2 inputs, optionally bipolar
Digital inputs
Digital outputs
With standard I/O
4 inputs optionally 1 frequenc y input single-track 0 ... 10 kHz or
double-track 0 ... 1 kHz
1 input for controller inhibit
1 output
With application I/O
6 inputs optionally 1 frequenc y input single-track/double-track 0 ...
100 kHz;
1 input for controller inhibit
2 outputs, 1 frequency output 50 Hz ... 10 kHz
Cycle times
Digital inputs 1ms
Digital outputs 4ms
Analog inputs 2msec
Analog outputs 4 ms (smoothing time: τ =10ms)
Relay output
0.25 ... 11 kW 1 relay output
(changeover contact)
AC 250 V/3 A, DC 24 V/2 A ... 240 V/0.16 A
15 ... 90 kW 2 relay outputs
(changeover contact)
AC 250 V/3 A, DC 24 V/2 A ... 240 V/0.22 A
Operation in generator
mode
0.25 ... 11 kW Integrated brake transistor
15 ... 90 kW With brake chopper 8253 or 9352
Inputs and outputs
