Lenze i510 Series

Parameter Name / value range / [default seng] Info
0x2949:001
(P337.01)
Posive torque limit source
(Pos. torqlim src)
•
From version 03.00
Selecon of the source for the posive torque limit source.
0 Max torque Posive torque limit source = Max torque 0x6072 (P326.00).
1 Fixed Limit 0.0 % Posive torque limit source = 0.0 %.
2 Analog Input 1 The posive torque limit source is dened as analog signal via the analog
input 1.
4Analog input 1 ^ 409
3 Analog Input 2 The posive torque limit source is dened as analog signal via the analog
input 2.
4Analog input 2 ^ 413
4 Posive torque limit Posive torque limit source = Posive torque limit 0x60E0.
5 Network target torque The posive torque limit source is dened as process data object via net-
work.
4Conguring the network ^ 172
0x2949:002
(P337.02)
Negave torque limit source
(Neg. torqlim src)
•
From version 03.00
Selecon of the source for the negave torque limit source.
0 (-) Max torque Negave torque limit source = (-) Max torque 0x6072 (P326.00).
1 Fixed Limit 0.0 % Negave torque limit source = 0.0 %.
2 Analog Input 1 The negave torque limit source is dened as analog signal via the ana-
log input 1.
4Analog input 1 ^ 409
3 Analog Input 2 The negave torque limit source is dened as analog signal via the ana-
log input 2.
4Analog input 2 ^ 413
4 Negave torque limit Negave torque limit source = Negave torque limit 0x60E1.
5 Network target torque The negave torque limit source is dened as process data object via
network.
4Conguring the network ^ 172
0x2C00
(P300.00)
Motor control mode
(Motor ctrl mode)
•
Seng can only be changed if the inverter is inhibi-
ted.
Selecon of the motor control type.
3 Sensorless control (SL PSM) (from
version 02.00)
This control type is used for the sensorless control of a synchronous
motor.
4Sensorless control for synchronous motors (SL-PSM) ^ 125
4 Sensorless vector control (SLVC) This control type is used for sensorless vector control of an asynchro-
nous motor.
4Sensorless vector control (SLVC) ^ 122
6 V/f characterisc control (VFC open loop) This control mode is used for the speed control of an asynchronous
motor via a V/f characterisc and is the simplest control mode.
4V/f characterisc control (VFC) ^ 116
0x6060
(P301.00)
Modes of operaon
(Modes of op.)
•
Seng can only be changed if the inverter is inhibi-
ted.
Selecon of the operang mode.
-2 MS: Velocity mode Vendor specic velocity mode
-1 MS: Torque mode (from version 03.00) Vendor specic torque mode
•
Only possible in motor control type 0x2C00 (P300.00) = "Sensorless
vector control (SLVC) [4]".
4Torque control w/ freq. limit ^ 153
0 No mode change/no mode assigned No operang mode (standsll)
2 CiA: Velocity mode CiA 402 velocity mode
Motor control
Motor control selecon
Sensorless vector control (SLVC)
123
