Lenze i510 Series Commissioning

Details
The operang range of an asynchronous motor consists of the voltage range
①
and the eld
weakening range. The eld weakening range again is divided into two ranges:
•
In the rst range
②
, the power can be kept constant without the motor stalling.
•
The second eld weakening range
③
is characterised by the fact that the maximum per-
missible stator current is decreased to prevent the motor from stalling .
Speed/torque curve of the asynchronous motor with two eld weakening ranges
0
0.2
0.3
0.4
0.5
0.6
0.7
0.8
0.9
1.0
0.1
1.1 1.2 1.3 1.4 1.5 1.6 1.7 1.8 1.9
2.0
0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
2.1 2.2 2.3 2.4 2.5 2.6 2.7 2.8 2.9 3.0 3.1 3.2 3.3 3.4
n
1
M = M
2 *
n ²/n²
2
M
2
n
2
M = M
max
M = M
max *
n
1
/n
The override point (n
2
, M
2
) can be inuenced with 0x2B0C (P319.00).
0x2B0C (P319.00) > 0 Hz:
•
The maximum current characterisc is shied to higher eld frequencies by the frequency
entered.
•
The maximum permissible current and the maximum torque increase in the eld weaken-
ing range.
•
The risk of motor stalling increases.
0x2B0C (P319.00) < 0 Hz:
•
The maximum current characterisc is shied to lower eld frequencies by the frequency
entered.
•
The maximum permissible current and the maximum torque are reduced in the eld weak-
ening range.
•
The risk of motor stalling is reduced.
Parameter Name / value range / [default seng] Info
0x2B0C
(P319.00)
Override eld weakening
(Field weak thold)
-599.0 ... [0.0] ... 599.0 Hz
Oset of the override point for eld weakening.
0x2B01:002
(P303.02)
V/f shape data: Base frequency
(V/f shape data: Base frequency)
Device for 50-Hz mains: 0 ... [50]* ... 1500 Hz
Device for 60-Hz mains: 0 ... [60]* ... 1500 Hz
* Default seng depending on the size.
Base voltage and base frequency dene the V/f rao and thus the gradi-
ent of the V/f characterisc.
•
The V/f base voltage is usually set to the rated motor voltage
0x2C01:007 (P320.07).
•
The V/f base frequency is usually set to the rated motor frequency
0x2C01:005 (P320.05).
Motor control
Opmisaon of motor control
Opmising the stalling behaviour
134
