Lenze i510 Series

Parameter Name / value range / [default seng] Info
0x4003
(P413.00)
MOP starng mode
(MOP startmode)
Selecon of the inial value which is used aer acvaon of the func-
on.
0 Last value The last MOP value is used as inial value. It is sll provided aer the
mains voltage has been switched o and on again.
Note: The last MOP value is saved in the internal EEPROM of the inver-
ter. If the memory module is transferred to a compable device, the last
MOP value will therefore not be accepted.
1 Starng value The starng value of the corresponding operang mode is used as inial
value:
•
0x4004:001 (P414.01) for the operang mode "MS: Velocity mode"
•
0x4004:002 (P414.02) for PID control
•
0x4004:003 (P414.03) for the operang mode "MS: Torque mode"
2 Minimum value The minimum value of the corresponding operang mode is used as ini-
al value:
•
0x2915 (P210.00) for the operang mode "MS: Velocity mode"
•
0x404E:001 (P605.01) for PID control
0x4004:001
(P414.01)
MOP starng values: Frequency
(MOP start value: Frequency)
0.0 ... [0.0] ... 599.0 Hz
Starng value for operang mode "MS: Velocity mode".
•
This value is used as inial value if "Starng value [1]" is set in 0x4003
(P413.00).
0x4004:002
(P414.02)
MOP starng values: PID value
(MOP start value: PID value)
-300.00 ... [0.00] ... 300.00 PID unit
Starng value for reference value of the PID control.
•
This value is used as inial value if "Starng value [1]" is set in 0x4003
(P413.00).
0x4004:003
(P414.03)
MOP starng values: Torque
(MOP start value: Torque)
0.0 ... [0.0] ... 1000.0 %
Starng value for operang mode "MS: Torque mode".
•
This value is used as inial value if "Starng value [1]" is set in 0x4003
(P413.00).
0x4009:001 MOP values saved: Frequency
•
Read only: x.x Hz
Display of the last MOP value saved internally for the operang mode
"MS: Velocity mode".
•
This value is used as inial value if "Last value [0]" is set in 0x4003
(P413.00).
0x4009:002 MOP values saved: PID value
•
Read only: x.xx PID unit
Display of the last MOP value saved internally for the reference value of
the PID control.
•
This value is used as inial value if "Last value [0]" is set in 0x4003
(P413.00).
0x4009:003 MOP values saved: Torque
•
Read only: x.x %
Display of the last MOP value saved internally for the operang mode
"MS: Torque mode".
•
This value is used as inial value if "Last value [0]" is set in 0x4003
(P413.00).
0x2915
(P210.00)
Minimum frequency
(Min. frequency)
0.0 ... [0.0] ... 599.0 Hz
Lower limit value for all frequency setpoints.
0x2916
(P211.00)
Maximum frequency
(Max. frequency)
Device for 50-Hz mains: 0.0 ... [50.0] ... 599.0 Hz
Device for 60-Hz mains: 0.0 ... [60.0] ... 599.0 Hz
Upper limit value for all frequency setpoints.
0x2919
(P222.00)
Acceleraon me 2
(Accelerat.me 2)
0.0 ... [5.0] ... 3600.0 s
Acceleraon me 2 for the operang mode "MS: Velocity mode".
•
The acceleraon me set refers to the acceleraon from standsll to
the maximum frequency set. In the case of a lower setpoint selecon,
the actual acceleraon me is reduced accordingly.
•
The acceleraon me 2 is acve if the frequency setpoint (absolute
value) ≥ auto switching threshold 0x291B (P224.00) or the trigger
assigned to the funcon "Acvate ramp 2" in 0x2631:039 (P400.39) =
TRUE.
•
The acceleraon me 2 is also used for changing the MOP setpoint
generated by the "motor potenometer" funcon.
•
Seng is not eecve in the operang mode 0x6060 (P301.00) =
"CiA: Velocity mode [2]". 4Device prole CiA 402 ^ 297
Flexible I/O conguraon
Setpoint change-over
Motor potenometer setpoint source (MOP)
379
