Lenze i510 Series

t
t
0 Hz
30 Hz
10 Hz
20 Hz
40 Hz
50 Hz
60 Hz
0 Hz
30 Hz
10 Hz
20 Hz
40 Hz
50 Hz
60 Hz
t
t
t
t
t
t
t
t
t
t
0x2DDD
Seq. controlled [100] Digital output 1
Seq. controlled [100] Relay
Seg2
t
Seg1
t
End seg
t
Seg2
t
Seg1
t
Bit 0 = 1 and bit 1 ... 3 = 0: sequence 1 is selected.
Sequence active [101]
Segment 2
(30 Hz)
Segment 1
(40 Hz)
End segment
(10 Hz)
Segment 2
(30 Hz)
Segment 1
(40 Hz)
Start sequenceDigital input 2 [12]
RunDigital input 1 [11]
Running [50]
Stop active [53]
Select sequence (bit 0)
Digital input 3 [13]
Constant TRUE [1]
Constant TRUE [1]
Output signals
Status signals
Output frequency
Abort sequence
Enable inverter
Input signals
Frequency setpoint selection
FunctionTrigger
The status signals can be assigned to digital outputs. 4Conguraon of digital outputs ^ 415
①
If the inverter is enabled and no error is acve, the motor can be started with the "Run" funcon.
As the sequence has not been started yet, rst the normal setpoint control is acve.
②
The "Start sequence" funcon is used to start the selected sequence in an edge-controlled way.
③
Sequencer mode 0x4025 (P800.00) = "Time operaon [1]":
The switch-over to the next step of the sequence is made aer the me set for the current segment has elapsed.
④
The segment 2 is congured here in such a way that the relay will be triggered during the me of processing.
⑤
End of sequence mode 0x402F (P824.00) = "Keep running [0]":
Aer the sequence has been processed, the setpoint set for the end segment is connuously transmied to the motor control unl the
sequence is aborted.
⑥
In case of the end segment, the me seng determines the delay aer which the congured output states are to become acve. Here, the
end segment is congured in such a way that the digital output 1 is set aer 10 s have expired.
⑦
If the "Run" funcon is set to FALSE, the motor is stopped with the stop method set in 0x2838:003 (P203.03). The started sequence, how-
ever, remains acve and the sequencer-controlled outputs keep their state.
⑧
Start of sequence mode 0x4040 (P820.00) = "Restart sequencer [0]":
If the "Run" funcon is set to TRUE again, the (sll acve) sequence is restarted.
⑨
The "Abort sequence" funcon is used to abort the sequence in an edge-controlled way.
In this case, the standard setpoint or the setpoint source selected via setpoint change-over is acve again.
Flexible I/O conguraon
Sequencer control funcons
