Lenze i510 Series

9024 0x2340 CiA: short circuit (inside the device) Keypad display: Motor shorted
Cause Error type/response Remedy
Short circuit of motor cable Fault
•
The inverter is inhibited immediately. The
motor becomes torqueless (coasts).
•
The error can only be reset aer a blocking
me of 5 s.
Check motor cable for short circuit.
9040 0x2350 CiA: i²*t overload (thermal state) Keypad display: i2t motor
Cause Error type/response Remedy
Error message is not available for the inverter
i510.
Motor thermally overloaded, e. g. by an imper-
missible connuous current or by frequent or
too long acceleraon processes.
Fault
•
The error can only be reset aer a blocking
me of 5 s.
•
The error type can be congured in 0x2D4B:
003 (P308.03).
•
Check drive dimensioning.
•
Check machine/driven mechanics for exces-
sive load.
Related topics
4Motor overload monitoring (i²*t) ^ 162
9090 0x2382 I*t error Keypad display: Ixt error
Cause Error type/response Remedy
Device ulisaon (I*t) too high by frequent and
too long acceleraon processes.
Fault
•
The inverter is inhibited immediately. The
motor becomes torqueless (coasts).
•
The error can only be reset aer a blocking
me of 3 s.
•
The error type can be congured in
0x2D40:005 (P135.05).
Check drive dimensioning.
Related topics
4Device overload monitoring (i*t) ^ 88
9091 0x2383 I*t warning Keypad display: Ixt warning
Cause Error type/response Remedy
Device ulisaon (I*t) too high by frequent and
too long acceleraon processes.
Warning Check drive dimensioning.
Related topics
4Device overload monitoring (i*t) ^ 88
9095 0x2387 Imax: Clamp responded too oen Keypad display: Clamp meout
Cause Error type/response Remedy
Maximum current of the axis (display in
0x2DDF:002) has been reached too oen in suc-
cession.
Fault
•
The inverter is inhibited immediately. The
motor becomes torqueless (coasts).
•
Select a aer speed ramp.
•
Reduce the load.
•
Set Imax controller more dynamically.
Related topics
4Imax controller ^ 151
9096 0x2388 SLPSM stall detecon acve Keypad display: SLPSM stall det.
Cause Error type/response Remedy
Overload of the motor with sensorless control
for synchronous motors (SL-PSM).
Trouble
•
The inverter is inhibited immediately. The
motor becomes torqueless (coasts).
•
Reduce load at the axis.
•
Check sengs of the SL-PSM parameters.
Related topics
4Sensorless control for synchronous motors (SL-PSM) ^ 125
Appendix
Error codes
440
