Lenze i510 Series

Error code Error message Error type Congurable in
30346 0x768A Memory module: wrong type Fault -
30352 0x7690 EPM rmware version incompable Fault -
30353 0x7691 EPM data: rmware type incompable Fault -
30354 0x7692 EPM data: new rmware type detected Fault -
30355 0x7693 EPM data: PU size incompable Fault -
30356 0x7694 EPM data: new PU size detected Fault -
30357 0x7695 Invalid conguraon of parameter change-over Warning -
30358 0x7696 EPM data: unknown parameter found Info -
30359 0x7697 Changed parameters lost Fault -
33045 0x8115 Time-out (PZÜ) No response 0x2552:004 (P595.04)
33154 0x8182 CAN: bus o Trouble 0x2857:010
33155 0x8183 CAN: warning Warning 0x2857:011
33156 0x8184 CAN: heartbeat me-out consumer 1 Fault 0x2857:005
33157 0x8185 CAN: heartbeat me-out consumer 2 Fault 0x2857:006
33158 0x8186 CAN: heartbeat me-out consumer 3 Fault 0x2857:007
33159 0x8187 CAN: heartbeat me-out consumer 4 Fault 0x2857:008
33185 0x81A1 Modbus: network me-out Fault 0x2858:001 (P515.01)
33186 0x81A2 Modbus: incorrect request by master Warning -
33425 0x8291 CAN: RPDO1 me-out Fault 0x2857:001
33426 0x8292 CAN: RPDO2 me-out Fault 0x2857:002
33427 0x8293 CAN: RPDO3 me-out Fault 0x2857:003
33553 0x8311 Torque limit reached No response 0x2D67:001 (P329.01)
36992 0x9080 Keypad removed Fault -
65285 0xFF05 Safe Torque O error Fault -
65286 0xFF06 Motor overspeed Fault 0x2D44:002 (P350.02)
65289 0xFF09 Motor phase missing No response 0x2D45:001 (P310.01)
65290 0xFF0A Phase U motor phase failure No response 0x2D45:001 (P310.01)
65291 0xFF0B Motor phase failure phase V No response 0x2D45:001 (P310.01)
65292 0xFF0C Motor phase failure phase W No response 0x2D45:001 (P310.01)
65305 0xFF19 Motor parameter idencaon error Fault -
65335 0xFF37 Automac start disabled Fault -
65366 0xFF56 Maximum motor frequency reached Warning -
65413 0xFF85 Keypad full control acve Warning -
Details regarding the individual error messages
8784 0x2250 CiA: connuous overcurrent (inside the device) Keypad display: PU over current
Cause Error type/response Remedy
•
Connuous overcurrent on the inverter/
motor side.
•
Overcurrent at the brake chopper (brake
transistor).
•
DC bus relay has not been closed due to a
malfuncon.
Fault
•
The inverter is inhibited immediately. The
motor becomes torqueless (coasts).
•
The error can only be reset aer a blocking
me of 5 s.
•
Check motor and wiring for short circuits.
•
Check brake resistor and wiring.
8992 0x2320 CiA: Short circuit/earth leakage (internal) Keypad display: Earth leak
Cause Error type/response Remedy
•
Short circuit/earth fault of motor cable
•
Capacive charging current of the motor
cable too high.
Fault
•
The inverter is inhibited immediately. The
motor becomes torqueless (coasts).
•
The error can only be reset aer a blocking
me of 5 s.
•
Check motor cable.
•
Check length of the motor cable.
•
Use shorter or lower-capacitance motor
cable.
Appendix
Error codes
439
