Lenze i510 Series

33156 0x8184 CAN: heartbeat me-out consumer 1 Keypad display: CAN heartb. C1
Cause Error type/response Remedy
Within the heartbeat me 0x1016:001
(P520.01), no heartbeat telegram was received
by node 1 to be monitored.
Fault
•
The error type can be congured in
0x2857:005.
•
Check communicaon with the heartbeat
producer.
•
Reacvate heartbeat producer.
Related topics
4Heartbeat protocol ^ 208
33157 0x8185 CAN: heartbeat me-out consumer 2 Keypad display: CAN heartb. C2
Cause Error type/response Remedy
Within the heartbeat me 0x1016:002
(P520.02), no heartbeat telegram was received
by node 2 to be monitored.
Fault
•
The error type can be congured in
0x2857:006.
•
Check communicaon with the heartbeat
producer.
•
Reacvate heartbeat producer.
Related topics
4Heartbeat protocol ^ 208
33158 0x8186 CAN: heartbeat me-out consumer 3 Keypad display: CAN heartb. C3
Cause Error type/response Remedy
Within the heartbeat me 0x1016:003
(P520.03), no heartbeat telegram was received
by node 3 to be monitored.
Fault
•
The error type can be congured in
0x2857:007.
•
Check communicaon with the heartbeat
producer.
•
Reacvate heartbeat producer.
Related topics
4Heartbeat protocol ^ 208
33159 0x8187 CAN: heartbeat me-out consumer 4 Keypad display: CAN heartb. C4
Cause Error type/response Remedy
Within the heartbeat me 0x1016:004
(P520.04), no heartbeat telegram was received
by node 4 to be monitored.
Fault
•
The error type can be congured in
0x2857:008.
•
Check communicaon with the heartbeat
producer.
•
Reacvate heartbeat producer.
Related topics
4Heartbeat protocol ^ 208
33185 0x81A1 Modbus: network me-out Keypad display: Modbus me-out
Cause Error type/response Remedy
No valid messages have been received via the
Modbus for a longer me than the me-out
me set in 0x2858:002 (P515.02).
Fault
•
The error type can be congured in
0x2858:001 (P515.01).
•
Check communicaon with the master.
•
Check wiring.
•
Check bus terminaon.
33186 0x81A2 Modbus: incorrect request by master Keypad display: Modbus request
Cause Error type/response Remedy
The request by the master is invalid, e. g. invalid
CRC checksum, non-supported funcon code,
or impermissible data access.
Warning
•
The inverter (slave) responds to the master
with an error code:
0x01 = invalid funcon code
0x02 = invalid data address
0x03 = invalid data value
0x04 = slave device failure
Check request by the master:
•
Value in the valid range?
•
Funcon code valid?
•
No impermissible write access? (e. g. with
regard to read-only parameters)
Appendix
Error codes
450
