Lenze i510 Series - Page 59

Display code Short designaon Default seng Seng range Address Category
└ P583.11 Last RxD byte9 - - (Read only) 0x232E:011 Modbus RTU
└ P583.12 Last RxD byte10 - - (Read only) 0x232E:012 Modbus RTU
└ P583.13 Last RxD byte11 - - (Read only) 0x232E:013 Modbus RTU
└ P583.14 Last RxD byte12 - - (Read only) 0x232E:014 Modbus RTU
└ P583.15 Last RxD byte13 - - (Read only) 0x232E:015 Modbus RTU
└ P583.16 Last RxD byte14 - - (Read only) 0x232E:016 Modbus RTU
└ P583.17 Last RxD byte15 - - (Read only) 0x232E:017 Modbus RTU
P585.xx Tx data diagn.
└ P585.01 Tx data oset 0 0 ... 240 0x232F:001 Modbus RTU
└ P585.02 Last TxD byte0 - - (Read only) 0x232F:002 Modbus RTU
└ P585.03 Last TxD Byte1 - - (Read only) 0x232F:003 Modbus RTU
└ P585.04 Last TxD byte2 - - (Read only) 0x232F:004 Modbus RTU
└ P585.05 Last TxD byte3 - - (Read only) 0x232F:005 Modbus RTU
└ P585.06 Last TxD byte4 - - (Read only) 0x232F:006 Modbus RTU
└ P585.07 Last TxD byte5 - - (Read only) 0x232F:007 Modbus RTU
└ P585.08 Last TxD byte6 - - (Read only) 0x232F:008 Modbus RTU
└ P585.09 Last TxD byte7 - - (Read only) 0x232F:009 Modbus RTU
└ P585.10 Last TxD byte8 - - (Read only) 0x232F:010 Modbus RTU
└ P585.11 Last TxD byte9 - - (Read only) 0x232F:011 Modbus RTU
└ P585.12 Last TxD byte10 - - (Read only) 0x232F:012 Modbus RTU
└ P585.13 Last TxD byte11 - - (Read only) 0x232F:013 Modbus RTU
└ P585.14 Last TxD byte12 - - (Read only) 0x232F:014 Modbus RTU
└ P585.15 Last TxD byte13 - - (Read only) 0x232F:015 Modbus RTU
└ P585.16 Last TxD byte14 - - (Read only) 0x232F:016 Modbus RTU
└ P585.17 Last TxD byte15 - - (Read only) 0x232F:017 Modbus RTU
P590.xx NetWordINx
└ P590.01 NetWordIN1 0x0000 0x0000 ... 0xFFFF 0x4008:001 general
└ P590.02 NetWordIN2 0x0000 0x0000 ... 0xFFFF 0x4008:002 general
└ P590.03 NetWordIN3 0.0 % 0.0 ... 100.0 % 0x4008:003 general
└ P590.04 NetWordIN4 0.0 % 0.0 ... 100.0 % 0x4008:004 general
P591.xx NetWordOUTx
└ P591.01 NetWordOUT1 - - (Read only) 0x400A:001 general
└ P591.02 NetWordOUT2 - - (Read only) 0x400A:002 general
P592.xx Process data IN
└ P592.01 AC control word 0x0000 0x0000 ... 0xFFFF 0x400B:001 general
└ P592.02 LECOM ctrl word 0x0000 0x0000 ... 0xFFFF 0x400B:002 general
└ P592.03 Net.freq. 0.1 0.0 Hz 0.0 ... 599.0 Hz 0x400B:003 general
└ P592.04 Net.setp. speed 0 rpm 0 ... 50000 rpm 0x400B:004 general
└ P592.05 Net.freq. 0.01 0.00 Hz 0.00 ... 599.00 Hz 0x400B:005 general
└ P592.06 Veloc. mode setp 0.0 Hz -599.0 ... 599.0 Hz 0x400B:006 general
└ P592.07 PID setpoint 0.00 PID unit -300.00 ... 300.00 PID unit 0x400B:007 general
└ P592.08 Torque mode setp 0 Nm -32768 ... 32767 Nm 0x400B:008 general
└ P592.09 Torque scaling 0 -128 ... 127 0x400B:009 general
└ P592.11 PID feedback 0.00 PID unit -300.00 ... 300.00 PID unit 0x400B:011 general
└ P592.12 NetSereq0.02Hz 0 Hz -29950 ... 29950 Hz 0x400B:012 general
└ P592.13 N.FrqSet+/-16384 0 -32768 ... 32767 0x400B:013 general
P593.xx Process data OUT
└ P593.01 AC status word - - (Read only) 0x400C:001 general
└ P593.02 LECOM stat. word - - (Read only) 0x400C:002 general
└ P593.03 Frequency (0.1) x.x Hz - (Read only) 0x400C:003 general
└ P593.04 Motor speed x rpm - (Read only) 0x400C:004 general
└ P593.05 Drive status - - (Read only) 0x400C:005 general
└ P593.06 Frequency 0.01 x.xx Hz - (Read only) 0x400C:006 general
└ P593.07 Torque scaled - - (Read only) 0x400C:007 general
* Default seng depending on the size. Firmware version 05.00.00.00
Commissioning
Keypad parameter list
59
