Lenze i510 Series

Display code Short designaon Default seng Seng range Address Category
└ P808.05 Analog outp. 0.00 VDC 0.00 ... 10.00 VDC 0x402D:005 general
└ P808.06 PID setp. 0.00 PID unit -300.00 ... 300.00 PID unit 0x402D:006 general
└ P808.07 Torque setp. 100.0 % -400.0 ... 400.0 % 0x402D:007 general
P820.00 StartOfSeq. mode Restart sequencr [0] Selecon list 0x4040 general
P822.xx End segment
└ P822.01 Frequency setp. 0.0 Hz -599.0 ... 599.0 Hz 0x402E:001 general
└ P822.02 Accel./decel. 5.0 s 0.0 ... 3600.0 s 0x402E:002 general
└ P822.03 Time 0.0 s 0.0 ... 100000.0 s 0x402E:003 general
└ P822.04 Digital outp. 0 0 ... 255 0x402E:004 general
└ P822.05 Analog outp. 0.00 VDC 0.00 ... 10.00 VDC 0x402E:005 general
└ P822.06 PID setp. 0.00 PID unit -300.00 ... 300.00 PID unit 0x402E:006 general
└ P822.07 Torque setp. 100.0 % -400.0 ... 400.0 % 0x402E:007 general
P824.00 End of seq. mode Keep running [0] Selecon list 0x402F general
P830.xx Sequence 1
└ P830.01 ... 16 Step 1 ... Step 16 Skip step [0] Selecon list 0x4030:001 ...
0x4030:016
general
P831.00 Cycl. sequence 1 1 1 ... 65535 0x4031 general
P835.xx Sequence 2
└ P835.01 ... 16 Step 1 ... Step 16 Skip step [0] Selecon list 0x4032:001 ...
0x4032:016
general
P836.00 Cycl. sequence 2 1 1 ... 65535 0x4033 general
P840.xx Sequence 3
└ P840.01 ... 16 Step 1 ... Step 16 Skip step [0] Selecon list 0x4034:001 ...
0x4034:016
general
P841.00 Cycl. sequence 3 1 1 ... 65535 0x4035 general
P845.xx Sequence 4
└ P845.01 ... 16 Step 1 ... Step 16 Skip step [0] Selecon list 0x4036:001 ...
0x4036:016
general
P846.00 Cycl. sequence 4 1 1 ... 65535 0x4037 general
P850.xx Sequence 5
└ P850.01 ... 16 Step 1 ... Step 16 Skip step [0] Selecon list 0x4038:001 ...
0x4038:016
general
P851.00 Cycl. sequence 5 1 1 ... 65535 0x4039 general
P855.xx Sequence 6
└ P855.01 ... 16 Step 1 ... Step 16 Skip step [0] Selecon list 0x403A:001 ...
0x403A:016
general
P856.00 Cycl. sequence 6 1 1 ... 65535 0x403B general
P860.xx Sequence 7
└ P860.01 ... 16 Step 1 ... Step 16 Skip step [0] Selecon list 0x403C:001 ...
0x403C:016
general
P861.00 Cycl. sequence 7 1 1 ... 65535 0x403D general
P865.xx Sequence 8
└ P865.01 ... 16 Step 1 ... Step 16 Skip step [0] Selecon list 0x403E:001 ...
0x403E:016
general
P866.00 Cycl. sequence 8 1 1 ... 65535 0x403F general
* Default seng depending on the size. Firmware version 05.00.00.00
Commissioning
Keypad parameter list
65
