Lenze i550

6 EtherNet/IP
Troubleshooting
46 Lenze · Inverter i550 - Cabinet · Ethernet Manual · 0.1 EN · 12/2015
6.10.2 EtherNet/IP specific messages
Error Code
(Hex)
Error Code
(Dec)
Fault Type
Tool text
Description
0x8190
33168
Configurable
(0x2859:1)
Watchdog
timeout
EtherNet/IP watchdog expired (Communication con-
nection detected a timeout)
0x8286
33414
Configurable
(0x2859:3)
PDO map error
EtherNet/IP PDO mapping error (fault with I/O data
configuration)
0x8192
33170
Configurable
(0x2859:4)
Net. Init. error
EtherNet/IP communication stack initialization error
(wrong setting during initialization)
0x8193
33171
Configurable
(0x2859:5)
Inv cycl data
EtherNet/IP invalid cyclic data (exchanged cyclic data is
static, not updated)
0x8112
33042
Configurable
(0x2859:6)
TO expl. msg
EtherNet/IP timeout explicit message (parameter
communication connection expired)
0x8114
33044
Configurable
(0x2859:7)
TO overall comm
EtherNet/IP overall communication timeout
