Lenze i550

7 Drive Profile
NETword Configuration
Lenze · Inverter i550 - Cabinet · Ethernet Manual · 0.1 EN · 12/2015 59
7.4.2 NETWordOut configuration
Actual value:
P591:1
0x400A:1
NetWordOUT1
i510
i550
R
Bit # description:
0: Mapping bit 0
1: Mapping bit 1
…
Actual value of mappable network out word 1 bit collector
(Status bits)
--> Trigger mapping 0x2634:1-3 (P420:1-3)
P591:2
0x400A:2
NetWordOUT2
i510
i550
R
Bit # description:
0: Mapping bit 0
1: Mapping bit 1
…
No mapping
Configuration:
P420:10
0x2634:10
NETWordOUT1 - bit 0
i510
i550
R/W
51:Ready for operation
(Reference see P420:1)
Function of Network Bit 0
P420:11
0x2634:11
NETWordOUT1 - bit 1
i510
i550
R/W
69:Inverse rotation
(Reference see P420:1)
Function of Network Bit 1
P420:12
0x2634:12
NETWordOUT1 - bit 2
i510
i550
R/W
50:Running
(Reference see P420:1)
Function of Network Bit 2
P420:13
0x2634:13
NETWordOUT1 - bit 3
i510
i550
R/W
56:Fault
(Reference see P420:1)
Function of Network Bit 3
P420:14
0x2634:14
NETWordOUT1 - bit 4
i510
i550
R/W
55:Safe Torque Off
(Reference see P420:1)
Function of Network Bit 4
P420:15
0x2634:15
NETWordOUT1 - bit 5
i510
i550
R/W
54:Quick stop active
(Reference see P420:1)
Function of Network Bit 5
P420:16
0x2634:16
NETWordOUT1 - bit 6
i510
i550
R/W
71:Actual speed = 0
(Reference see P420:1)
Function of Network Bit 6
P420:17
0x2634:17
NETWordOUT1 - bit 7
i510
i550
R/W
58:Device warning
(Reference see P420:1)
Function of Network Bit 7
P420:18
0x2634:18
NETWordOUT1 - bit 8
i510
i550
R/W
115:Holding brake release
(Reference see P420:1)
Function of Network Bit 8
P420:19
0x2634:19
NETWordOUT1 - bit 9
i510
i550
R/W
78:At current limit
(Reference see P420:1)
Function of Network Bit 9
P420:20
0x2634:20
NETWordOUT1 - bit 10
i510
i550
R/W
72:Setpoint speed reached
(Reference see P420:1)
Function of Network Bit 10
