Parameter access data channel

AC DRIVE profile

Minimum Fieldbus cycle time
(Request Packet Interval - RPI)
4 ms
Fieldbus cycle time steps
4-128 msec
Pass through time Frame to axis ms
<= 6 ms
Port to Port latency
<= 125 us
Feature
Inverter Drive
Internet Protocol (IP version 4) (RFC 791)

DLR (Device Level Ring Protocol)

DLR supervisor mode
-
User Datagram Protocol (UDP) (RFC 768)

Transmission Control Protocol (TCP) (RFC 793)

Address Resolution Protocol (ARP) (RFC 826)

Internet Control Messaging Protocol (ICMP) (RFC
792)

ACD (Address Conflict Detection)

QoS (Quality of Service)

IEEE 802.3 (Ethernet) (RFC 894)

6.2 Configuration
Each node on the network must have an individual address, if two or more nodes have duplicate addresses the
network will not function correctly. After changing this setting, the drive must be power cycled or the Ether-
Net/IP module must be reset in order for the new IP address to take effect.

See chapter 2.2 Rotary Selector (EtherNet/IP, EtherCAT only) on page 7 for details about rotary switch.
P508:0
0x23A0:0
Activate network (*)
i550
R/W
0: No action/no error
1: Restart with actual values
2: Restart with default values
5: Stop network communication
10: In progress
11: Action cancelled
12: Fault
Controls Network activities
P510:1
0x23A1:1
IP address (*)
i550
R/W
-- ... [192.168.124.16] ... --
EtherNet/IP address settings
