Lenze L-force CANopen EMF2178IB User Manual

Codes
Communication−relevant Lenze codes
14
l
121
EDSMF2178IB EN 3.0
C1822:
AIF−IN all words
Code Subcode Index
Possible settings
Data type
Lenze Selection
C1822 /1:
...
/12:
22753 =
0x58E1
g U16
All AIF−IN words as 16−bit values
C1823:
AIF−OUT all words
Code Subcode Index
Possible settings
Data type
Lenze Selection
C1823 /1:
...
/12:
22752 =
0x58E0
g U16
All AIF−OUT words as 16−bit values
C1824:
AIF−IN all double words
Code Subcode Index
Possible settings
Data type
Lenze Selection
C1824 /1:
...
/11:
22751 =
0x58DF
g U32
All AIF−IN double words as 32−bit values, with an offset of 16 bits each.
(¶ 66)
C1825:
AIF−OUT all double words
Code Subcode Index
Possible settings
Data type
Lenze Selection
C1825 /1:
...
/11:
22750 =
0x58DE
g U32
All AIF−OUT double words as 32−bit values, with an offset of 16 bits each.
(¶ 66)
