Parameter data transfer
Access to the codes of the controller
10
l
70
EDSMF2178IB EN 3.0
10.1 Access to the codes of the controller
When using Lenze communication modules, you can change the features and response
characteristics of any controller connected to the network using a higher−level host
system(PLC, master).
In Lenze controllers, parameters to be changed are listed under codes.
Controller codes are addressed via the index when accessing the code through the
communication module.
The index for Lenze code numbers is between 16576 (0x40C0) and 24575 (0x5FFF).
, Documentation for the controller
Here you can find a detailed description of the codes.
Indexing of Lenze codes
Conversion formula
Index (dec) Index (hex)
24575 − Lenze code 0x5FFF − (Lenze code)
hex
Example for C0001 (operating mode)
Index (dec) Index (hex)
24575 − 1 = 24574 0x5FFF − 1 = 0x5FFE
The parameter value is part of the telegram user data (see examples, ^ 77).
