Commissioning
Before switching on
6
l
32
EDSMF2178IB EN 3.0
6 Commissioning
During commissioning, system−dependent data as e.g. motor parameters, operating
parameters, responses and parameters for fieldbus communication are selected for the
controller.
In Lenze devices, this is done via codes. The codes are stored in numerically ascending order
in the Lenze controllers and in the plugged−in communication/function modules.
In addition to these configuration codes, there are codes for diagnosing and monitoring
the bus devices.
6.1 Before switching on
( Stop!
Before you switch on the standard device with the communication module for
the first time, check
ƒ the entire wiring with regard to completeness, short circuit, and earth fault.
ƒ whether the bus system is terminated by a bus terminating resistor at the
physically first and last node.
6.2 Installing EDS files
The EDS files serve to implement the Lenze communication modules for the AIF and FIF
interfaces into the CANopen configuration software.
The single EDS files describe the implemented CANopen functions of the respective
communication module and the "on board" Lenze system bus (CAN).
I Tip!
The current EDS file required for configuring the EMF2178IB (CANopen)
communication module can be found in the download area on:
www.Lenze.com
