4 Technical data
4.1 General data and operating conditions
Field Values
Order designation EMF2178IB
Communication media DIN ISO 11898
Network topology Line terminated at both ends (R = 120 W)
Communication profile CANopen, DS301 V4.01
Node addresses Max. 127
Cable length Max. 7450 m (depending on the baud rate, ^ 27)
Baud rate [kbit/s] 10, 20, 50, 125, 250, 500, 1000
Voltage supply
Internal or external supply possible for basic devices: 8200 vector / 93XX /
9300 Servo PLC / Drive PLC / ECSXX
(also see ^ 30)
External supply via separate power supply unit:
V+: V = 24 V DC ± 10 %
I = 100 mA
GND:
Reference potential for external voltage supply
, Documentation for Lenze series of devices 8200 vector, 9300 and ECS
Here you can find the ambient conditions and the electromagnetic
compatibility (EMC) specifications applying to the communication module.
