Product description
Connections and interfaces
3
l
16
EDSMF2178IB EN 3.0
3.4 Connections and interfaces
2178
Address Bd
CANopen
L
0
5
4
1
6
2
3
EMF2178IB
CAN_L
SHLD
V+
CAN_H
GND
2178CAN003
2102LEC007
Legend for fold−out page
Pos. Description Detailed
information
0 Connection status to standard device (two−colour LED)
^ 89
1 Connection status to fieldbus (two−colour LED)
2 Operating status of standard device (green and red Drive LED)
3 Fixing screw
4 Plug connector with double screw connection, 5−pole ^ 24
5 PE shield cable connection
6 DIP switches for setting the
l node address (switches 1 ... 7)
l baud rate (switches 8 ... 10)
^ 33
8 Nameplate ^ 14
