Technical data
Dimensions
4
l
20
EDSMF2178IB EN 3.0
4.4 Dimensions
2178
Address Bd
CANopen
L
CAN_L
SHLD
V+
CAN_H
GND
62
18
36
75
2178CAN003
Fig. 4−1 Dimensions of the communication module (all dimensions in mm)
