Codes
Communication−relevant Lenze codes
14
l
123
EDSMF2178IB EN 3.0
C1850/C2350:
CAN node address
Code Subcode Index
Possible settings
Data type
Lenze Selection
C1850 − 22725 =
0x58C5
1 1 [1] 99 FIX32
C2350 − 22225 =
0x56D1
This code serves to set the CAN node address of the communication module.
) Note!
ƒ If several CAN nodes are interconnected, their node addresses must differ
from each other.
ƒ Node addresses > 99 can only be set via DIP switch(¶ 33).
ƒ All DIP switches 1 ... 7 = OFF (Lenze setting):
– When the device is switched on, the settings under code C1850/C2350
(node address) and C1851/C2351 (baud rate) are active.
– Code C1850/C2350 is an image of code C0009 of the basic device. Setting
C1850/C2350 has a direct effect on C0009.
