Mechanical installation
Standard devices in t he power range 3 ... 22 kW
Assembly without filter in ”standard” technique
5

114
EDS84ASC552 EN 10.0
StateLine, HighLine
8400GG106g
Fig. 5-20 Dimensions for mounting
d
1
d
2
d
3
c c
1
c
2
c
3
i j
11
j
21
[kW] [mm] [kg]
E84AVxxE3024xXx3
9 9 285 20 10 10 120 0 >95 >95 4.4
E84AVxxE4024xXx 4
E84AVxxE5524xXx 5.5
E84AVxxE7524xXx 7.5
10 9 340 20 10 10 120 0 >95 >95 5.8
E84AVxxE1134xXx 11
E84AVxxE1534xXx 15
E84AVxxE1834xXx 18.5
11 8 340 25 12.5 12.5 180 0 >95 >95 12.0
E84AVxxE2234xXx 22
E84AVxxE3024xBx 3
9 9 285 20 10 10 120 0 >95 >95 4.5
E84AVxxE4024xBx 4
E84AVxxE5524xBx 5.5
E84AVxxE7524xBx 7.5
10 9 340 20 10 10 120 0 >95 >95 5.9
E84AVxxE1134xBx 11
E84AVxxE1534xBx 15
E84AVxxE1834xBx 18.5
11 8 340 25 12.5 12.5 180 0 >95 >95 12.1
E84AVxxE2234xBx 22
