Lenze L-force E84A Series - Page 115

Mechanical installation
Standard devices in t he power range 3 ... 22 kW
Assembly without filter in ”standard” technique
5

115
EDS84ASC552 EN 10.0
TopLine
8400GG106i
Fig. 5-21 Device dimensions
h b t h
1
h
2
t
1
t
2
g
1
g
2
g
3
[kW] [mm]
E84AVTCE3024xXx3
270 140 214 303 360 201 240 6 11 12
E84AVTCE4024xXx 4
E84AVTCE5524xXx 5.5
E84AVTCE7524xXx 7.5
325 140 214 359 416 201 240 6 11 12
E84AVTCE1134xXx 11
E84AVTCE1534xXx 15
E84AVTCE1834xXx 18.5
350 205 265 359 430 252 291 7 10 13
E84AVTCE2234xXx 22
E84AVTCE3024xBx 3
270 140 234 303 360 221 260 6 11 12
E84AVTCE4024xBx 4
E84AVTCE5524xBx 5.5
E84AVTCE7524xBx 7.5
325 140 234 359 416 221 260 6 11 12
E84AVTCE1134xBx 11
E84AVTCE1534xBx 15
E84AVTCE1834xBx 18.5
350 205 285 359 430 272 311 7 10 13
E84AVTCE2234xBx 22
