Mechanical installation
Standard devices in t he power range 3 ... 22 kW
Mounting i n ”cold plate” technique
5

136
EDS84ASC552 EN 10.0
TopLine
8400GG107c
Fig. 5-39 Device dimensions
h b t h
1
h
2
b
1
t
1
t
2
g
1
g
2
[kW] [mm]
E84AVTCC7524xXx7.5
325 174 156 378 426 140 143 182 6 5
E84AVTCC1134xXx 11
E84AVTCC1534xXx 15
E84AVTCC1834xXx 18.5
350 231 179 407 458 205 166 205 6 7
E84AVTCC2234xXx 22
E84AVTCC7524xBx 7.5
325 174 176 378 426 140 163 202 6 5
E84AVTCC1134xBx 11
E84AVTCC1534xBx 15
E84AVTCC1834xBx 18.5
350 231 199 407 458 205 186 225 6 7
E84AVTCC2234xBx 22
