Mechanical installation
Standard devices in a power range of 30 ... 45 kW
Assembly without filter in ”standard” technique
5

140
EDS84ASC552 EN 10.0
StateLine, HighLine
8400GG108d
Fig. 5-42 Dimensions for mounting
d
1
d
2
d
3
c c
1
c
2
c
3
i j
11
j
21
[kW] [mm] [kg]
E84AVxxE3034xXx30
8 12 500 40 20 20 210 0 >95 > 120 17.2
E84AVxxE3734xXx 37
E84AVxxE4534xXx 45
E84AVxxE3034xBx 30
8 12 500 40 20 20 210 0 >95 > 120 17.3
E84AVxxE3734xBx 37
E84AVxxE4534xBx 45
