Lenze L-force E84A Series - Page 21

Product description
Overview of standard devices
3

21
EDS84ASC552 EN 10.0
Connection Information
Pos. Description 230 V 400 V
X80 Terminal strip for the integrated safety unit  272
X100 Mains/DC-bus voltage (for 400 V devices)
– For devices in device size 6 (18.5 ... 22 kW) the terminal strip
is not pluggable.
 184  194
X101 Relay output  221
X105 Motor/external brake resistor
– For devices in device size 6 (18.5 ... 22 kW) the terminal strip
is not pluggable.
 188  198
X106 Motor temperature monitoring  187  199
IT Contact screw for interference suppression (on the supply
side/on the motor side)
 185  196
MCI Slot for communication module (Module Communication
Interface)
 296
 Sticker with w arning -
