Technical data
Rated data
Operation with increased power at a 230 V mains
4

55
EDS84ASC552 EN 10.0
Assignment of external mains chokes
Assignment
Type Mains choke required Mains choke
E84AVxxx2512 no ELN1-0900H005
E84AVxxx3712 yes ELN1-0900H005
E84AVxxx5512 no ELN1-0500H009
E84AVxxx7512 yes ELN1-0500H009
E84AVxxx1122 no ELN1-0250H018
E84AVxxx1522 yes ELN1-0250H018
E84AVxxx2222 - -
Switching frequency-dependent output currents
Output currents [A] at switching frequency
2kHz 4kHz 8kHz 16 kHz
Type I
arated2
I
aM2
I
arated4
I
aM4
I
arated8
I
aM8
I
arated16
I
aM16
E84AVxxx2512 2.1 3.4 2.1 3.4 - - - -
E84AVxxx3712 2.9 4.8 2.9 4.8 - - - -
E84AVxxx5512 3.6 6.0 3.6 6.0 - - - -
E84AVxxx7512 4.8 8.0 4.8 8.0 - - - -
E84AVxxx1122 6.8 11.0 6.8 11.0 - - - -
E84AVxxx1522 8.4 14.0 8.4 14.0 - - - -
E84AVxxx2222 - - - - - - - -
