Device parameters and interfaces
Leuze electronic BPS 34 49
TNT 35/7-24V
M12
Page 70
Status
(I) Measurement error
(I) Range state (outside of measurement range)
(I) Preset active
(I) Dynamic preset teach
(I) State
(I) Position limit value status 1
(I) Position limit value status 2
(I) Standby status
M13
Page 71
Min./max. position
(P) Min./max. mode
(P) Min./max. duration
(I) Min. position
(I) Max. position
(O) Min./max. reset
M14
Page 73
Static position limit
value 1
(P) Limit value check on/off
(P) Switching type (value is above or below the
defined limits)
(P) Hysteresis
(P) Limit value
M15
Page 74
Static position limit
value 2
(P) Limit value check on/off
(P) Switching type (value is above or below the
defined limits)
(P) Hysteresis
(P) Limit value
M16
Page 75
Dynamic position limit
value 1
(P) Limit value check on/off
(P) Switching type (value is above or below the
defined limits)
(P) Hysteresis
(O) Limit value
M17
Page 76
Dynamic position limit
value 2
(P) Limit value check on/off
(P) Switching type (value is above or below the
defined limits)
(P) Hysteresis
(O) Limit value
M18
Page 77
Measurement error tol-
erance
(P) Position tolerance time
(P) Error output delay
M19
Page 78
Service
(I) Status
(O) Reset to factory settings
M20
Page 79
Speed (I) Current speed
M21
Page 80
Speed parameters
(P) Resolution
(P) Scaling factor
(P) Integration depth
(P) Tolerance time (on error message)
(P) Error output delay
Module
Page
Module name Module contents
(P) = Parameter, (O) = Output, (I) = Input
