LevelOne WBR-6013 - Page 11

11
* Actual button may vary depending on model.
Figure 3: RESET button
Label
Function
ANTENNA
2 fixed ANTENNA
POWER
Connects to the supplied power adaptor
ON/OFF SWITCH
Power on / off the device
LAN 4/3/2/1
Connects the device via LAN Ethernet to up to 4 PCs
WAN
Connects the device via WAN Ethernet to xDSL / Cable
Modem
WPS
Press this button for at least 3 full seconds and the
WPS LED will flash to start WPS.
Now go to the wireless adapter or device and press its
WPS button. Make sure to press the button within 120
seconds (2 minutes) after pressing the router's WPS
button.
WLAN
Press this button for at least 3 full second to turn off/on
wireless signals
RESET
Reset button. RESET the WBR-6013 to its default
settings.
Press this button for at least 6 full seconds to RESET
device to its default settings.
