Lexmark E352DN Service Manual

Index I-1
4512-420, -430
Index
A
abbreviations 1-9
acronyms 1-9
autocompensator tires 4-38
C
cables
fuser power cable
4-24
Charge Roll, diagnostics mode 3-21
compatibility 1-5
configuration ID 3-20
configuration menu—
accessing
3-1
Demo Mode 3-3
Energy Conserve 3-3
entering 3-2
Exit Config Menu 3-4
Factory Defaults 3-3
menus 3-2
Panel Menus 3-3
PPDS Emulation 3-3
Prt Quality Pgs 3-3
Reset PC Cnt 3-2
control panel 1-2
controller card
removal
4-13
service check 2-17
D
Defaults
US/Non-US defaults
3-19
Demo Mode 3-3
diagnostic information 2-1
diagnostics mode— 3-1
available tests 3-5
Base Sensor Test 3-18
EP Setup
Charge Roll
3-21
EP Defaults 3-21
Fuser Temp 3-21
Gap Adjust 3-21
Print Contrast 3-21
Transfer 3-21
Event Log
Clear Log
3-22
Display Log 3-21
Print Log 3-22
Exit Diagnostics 3-22
exiting 3-6
Hardware Tests
Button Test
3-15
DRAM Test 3-15
LCD Test 3-15
Input Tray Tests
Feed Tests
3-17
Sensor Test 3-18
menu list 3-5
Print Tests
input source
3-14
input source tests 3-14
Prt Quality Pgs 3-14
Printer Setup
Configuration ID
3-20
Defaults 3-19
Edge to Edge 3-20
Engine Settings 3-20
Model Name 3-20
Page Count 3-19
Par S Strobe Adj 3-20
Perm Page Count 3-19
Serial Number 3-20
Registration 3-7
Quick Test 3-14
DRAM Test 3-15
E
Edge to Edge 3-20
Energy Conserve 3-3
EP Defaults 3-21
error log
clear log (diagnostics mode)
3-22
display log (diagnostics mode) 3-21
Print Log 3-22
error messages
service error codes
2-12
user attendance messages 2-5
ESD-sensitive parts 4-1
F
Factory Defaults 3-3
fan
parts catalog
7-5
removal 4-21
service check 2-18
frame, parts catalog 7-6
fuser
parts catalog
7-5
removal 4-22
service check 2-19
Fuser Temp 3-21
G
Gap Adjust 3-21
H
handling ESD-sensitive parts 4-1
History
see error log
3-22

Lexmark E352DN Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	2400 x 2400 DPI
Time to first page (black, normal)	6.5 s
Print speed (black, normal quality, A4/US Letter)	33 ppm
Internal memory	32 MB
Maximum internal memory	160 MB
Sound pressure level (printing)	52 dB
Total input capacity	250 sheets
Maximum input capacity	800 sheets
Envelopes sizes	7 3/4, 9, 10, B5, C5, DL
Maximum print size	210 x 297 mm
Media weight (tray 1)	80 gsm
Paper tray media types	Envelopes, Labels, Plain paper
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Statement (140 x 216mm), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
Maximum ISO A-series paper size	A4
Supported network protocols (IPv4)	TCP/IP IPv4, AppleTalk, TCP/IP IPv6
Compatible operating systems	Mac OS X Mac OS 9.x Citrix MetaFrame Linux Microsoft Windows 2000, NT, Me, XP, Server 2003, 98, Vista Novell UNIX
Maximum duty cycle	80000 pages per month
Sustainability certificates	ENERGY STAR
Operating altitude	0 - 2500 m
Operating temperature (T-T)	16 - 32 °C
Operating relative humidity (H-H)	8 - 80 %
Certification	FCC Class B, UL 60950-1, U.S. FDA, IEC 320-1, CSA, ICES Class B, CE Class B, CB IEC 60950-1, IEC 60825-1, GS (TÜV), SEMKO, UL AR, CS, TÜV Rh, N Mark, ACA C-tick Class B, CCC Class B, BSMI Class B, MIC, EK Mark, PSB

Weight and Dimensions

Dimensions (WxDxH)	396 x 359 x 259.5 mm
