Lexmark E352DN Service Manual

Diagnostics information 2-25
4512-420, -430
Black page
Note: Incorrect laser exposure or incorrect charging of the photoconductor causes an all black page. Always
verify the same results from a different print cartridge assembly and developer before proceeding.
Heavy background
Poor development or poorly charged toner particles cause excessive background. This is more noticeable as the
toner cartridge nears end-of-life.
FRU Action
Toner electrodes (not a
FRU)
Check the three rearward electrodes below the print cartridge assembly for contamination
or damage. Correct as necessary.
Check continuity between the cable (DEV, TAR, and doctor blade) connection PCN3 and on
the contact tips below the print cartridge assembly.
• If continuity fails, call the next level of service.
LVPS/HVPS board
Controller card
Miscellaneous cables
With the printer off, disconnect the LVPS/HVPS cable from J19 on the controller card.
Turn the printer on, and verify +24 V dc on pins 8 and 9 of the cable.
Verify ground on pins 7, 12, and 14.
• If the voltage is incorrect, replace LVPS/HVPS board.
• If grounds are incorrect, check ground paths.
• Check confinuity in the cable. Replace the cable if necessary.
• If voltage is correct and the toner electrodes are good, replace the controller card.
• See the “LVPS/HVPS service check” on page 2-20 and the “Controller card service
check” on page 2-17, if necessary.
FRU Action
Toner cartridge (not a
FRU)
PC Kit (not a FRU)
Check the toner darkness setting in the driver. Try a lower setting.
Make sure the toner cartridge and PC Kit are correctly installed and the high voltage
contacts are clean.
If the toner cartridge and PC Kit are installed correctly, try a new PC Kit first and then toner
cartridge.
LVPS/HVPS
Controller card
Check the contacts for correct installation and contamination where contact is made
between the print cartridge assembly and spring contacts which connect to the LVPS/HVPS
board at PCN3. Clean as necessary.
If this does not correct the problem, replace the following FRUs one at a time in the order
shown:
• LVPS/HVPS board (See “Black page” on page 3-25 for pin values.)
• Controller card

Lexmark E352DN Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	2400 x 2400 DPI
Time to first page (black, normal)	6.5 s
Print speed (black, normal quality, A4/US Letter)	33 ppm
Internal memory	32 MB
Maximum internal memory	160 MB
Sound pressure level (printing)	52 dB
Total input capacity	250 sheets
Maximum input capacity	800 sheets
Envelopes sizes	7 3/4, 9, 10, B5, C5, DL
Maximum print size	210 x 297 mm
Media weight (tray 1)	80 gsm
Paper tray media types	Envelopes, Labels, Plain paper
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Statement (140 x 216mm), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
Maximum ISO A-series paper size	A4
Supported network protocols (IPv4)	TCP/IP IPv4, AppleTalk, TCP/IP IPv6
Compatible operating systems	Mac OS X Mac OS 9.x Citrix MetaFrame Linux Microsoft Windows 2000, NT, Me, XP, Server 2003, 98, Vista Novell UNIX
Maximum duty cycle	80000 pages per month
Sustainability certificates	ENERGY STAR
Operating altitude	0 - 2500 m
Operating temperature (T-T)	16 - 32 °C
Operating relative humidity (H-H)	8 - 80 %
Certification	FCC Class B, UL 60950-1, U.S. FDA, IEC 320-1, CSA, ICES Class B, CE Class B, CB IEC 60950-1, IEC 60825-1, GS (TÜV), SEMKO, UL AR, CS, TÜV Rh, N Mark, ACA C-tick Class B, CCC Class B, BSMI Class B, MIC, EK Mark, PSB

Weight and Dimensions

Dimensions (WxDxH)	396 x 359 x 259.5 mm
