Lexmark E352DN Service Manual

Diagnostics information 2-19
4512-420, -430
Dead machine service check
CAUTION: Check the AC line voltage. The voltage should be within the following limits:
• 100 V ac (volts alternating current) – 127 V ac for the 110 V printer
• 200 V ac – 240 V ac for the 220 V printer
Fuser service check
When toner is partially fused to the media, it is usually caused by low fuser temperature.
The line voltage to the printer must be within the following limits:
• 100 V ac–127 V ac for the 110 V model printer
• 200 V ac–240 V ac for the 220 V model printer
This printer uses a belt fuser and therefore does not have a lamp.
FRU Action
LVPS/HVPS
Unplug the printer. Remove the LVPS/HVPS, and check the fuses for continuity.
• If open, replace the LVPS/HVPS.
• If not open, check the switch continuity across its conductors with the switch on. Turn
the switch off. Plug the AC line into the LVPS/HVPS and switch unit on.
Note: Voltages may be exposed at several places on the board. Do these verifications, and
then unplug the card:
• Verify 24 V dc on pins 8, 9, and 10 at PCN1.
• Verify approximately 3V on pins 1–3.
• Verify approximately 5V on pins 4 and 13.
• If voltages are not correct, replace the LVPS/HVPS.
• If voltages are correct, check the controller card. See “Controller card
service check” on page 2-17.
Fuser service check
FRU Action
Fuser power cable
LVPS/HVPS
Fuser
Unplug the printer, and disconnect the fuser cable plug from the LVPS/HVPS board
connector at PCN5.
Check for continuity across the fuser by checking across the connector pins.
• If there is continuity, check the LVPS/HVPS. See “LVPS/HVPS service check” on
page 3-20.
• If there is no continuity, disconnect the fuser power cable at both ends and check each
conductor for continuity. Replace cable if necessary.
• If the cable tests good, replace the fuser.
Make sure the fuser thermistor is correctly connected to the controller board at J13. If the
problem persists, disconnect the thermistor cable and check for less than +5 V dc on pin 1.
Pin 2 should be ground. If line voltage is incorrect on pin 1, see “Controller card service
check” on page 2-17 for more information.
Fuser
Disconnect the thermistor cable from J13 on the controller card.
Measure the resistance across the ends of the thermistor cable.
Replace the fuser assembly if the resistance is lower than 1K ohm or shorted.
Note: Resistance measures approximately 400K ohms when cool and 1K ohms hot.

Lexmark E352DN Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	2400 x 2400 DPI
Time to first page (black, normal)	6.5 s
Print speed (black, normal quality, A4/US Letter)	33 ppm
Internal memory	32 MB
Maximum internal memory	160 MB
Sound pressure level (printing)	52 dB
Total input capacity	250 sheets
Maximum input capacity	800 sheets
Envelopes sizes	7 3/4, 9, 10, B5, C5, DL
Maximum print size	210 x 297 mm
Media weight (tray 1)	80 gsm
Paper tray media types	Envelopes, Labels, Plain paper
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Statement (140 x 216mm), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
Maximum ISO A-series paper size	A4
Supported network protocols (IPv4)	TCP/IP IPv4, AppleTalk, TCP/IP IPv6
Compatible operating systems	Mac OS X Mac OS 9.x Citrix MetaFrame Linux Microsoft Windows 2000, NT, Me, XP, Server 2003, 98, Vista Novell UNIX
Maximum duty cycle	80000 pages per month
Sustainability certificates	ENERGY STAR
Operating altitude	0 - 2500 m
Operating temperature (T-T)	16 - 32 °C
Operating relative humidity (H-H)	8 - 80 %
Certification	FCC Class B, UL 60950-1, U.S. FDA, IEC 320-1, CSA, ICES Class B, CE Class B, CB IEC 60950-1, IEC 60825-1, GS (TÜV), SEMKO, UL AR, CS, TÜV Rh, N Mark, ACA C-tick Class B, CCC Class B, BSMI Class B, MIC, EK Mark, PSB

Weight and Dimensions

Dimensions (WxDxH)	396 x 359 x 259.5 mm
