Lexmark E352DN Service Manual

Diagnostic aids 3-1
4512-420, -430
3. Diagnostic aids
Accessing service menus
There are two different test menus that can be accessed during POR to identify problems with the printer.
Printing menus
To print a listing of the states and settings of the printer:
1. At the Ready prompt, press under Menu until Utilities appears.
2. Press .
3. Press until Print Menus appear.
4. Press .
Configuration Menu 1. Turn off the printer.
2. Press and hold and Back .
3. Turn on the printer.
4. Release the buttons when Performing
Self Test displays.
5. The message CONFIG MENU displays on
the top line of the operator panel.
The Configuration menu group contains a set
of menus, settings and operations which are
infrequently required by a user. Generally, the
options made available in this menu group are
used to configure a printer for operation.
See “Available menus” on page 3-2.
Diagnostics Mode 1. Turn off the printer.
2. Press and hold Go and Back .
3. Turn on the printer.
4. Release the buttons when Performing
Self Test displays.
The Diagnostic menu group contains the
settings and operations used while
manufacturing and servicing the printer.
See “Available tests” on page 3-5.

Lexmark E352DN Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	2400 x 2400 DPI
Time to first page (black, normal)	6.5 s
Print speed (black, normal quality, A4/US Letter)	33 ppm
Internal memory	32 MB
Maximum internal memory	160 MB
Sound pressure level (printing)	52 dB
Total input capacity	250 sheets
Maximum input capacity	800 sheets
Envelopes sizes	7 3/4, 9, 10, B5, C5, DL
Maximum print size	210 x 297 mm
Media weight (tray 1)	80 gsm
Paper tray media types	Envelopes, Labels, Plain paper
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Statement (140 x 216mm), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
Maximum ISO A-series paper size	A4
Supported network protocols (IPv4)	TCP/IP IPv4, AppleTalk, TCP/IP IPv6
Compatible operating systems	Mac OS X Mac OS 9.x Citrix MetaFrame Linux Microsoft Windows 2000, NT, Me, XP, Server 2003, 98, Vista Novell UNIX
Maximum duty cycle	80000 pages per month
Sustainability certificates	ENERGY STAR
Operating altitude	0 - 2500 m
Operating temperature (T-T)	16 - 32 °C
Operating relative humidity (H-H)	8 - 80 %
Certification	FCC Class B, UL 60950-1, U.S. FDA, IEC 320-1, CSA, ICES Class B, CE Class B, CB IEC 60950-1, IEC 60825-1, GS (TÜV), SEMKO, UL AR, CS, TÜV Rh, N Mark, ACA C-tick Class B, CCC Class B, BSMI Class B, MIC, EK Mark, PSB

Weight and Dimensions

Dimensions (WxDxH)	396 x 359 x 259.5 mm
