Lexmark E352DN Service Manual

3-14 Lexmark™ E350d, E352dn
4512-420, -430
Quick Test
The Quick Test contains the following information:
• Print registration settings
• Alignment diamonds at the top and bottom
• Horizontal lines to check for skew
• General printer information, including current page count, installed memory, serial number,
and code level.
To print the Quick Test page:
Note: Print the Quick Test Page on letter or A4 paper.
1. Select REGISTRATION from the Diagnostics menu.
2. Press Go.
Once the Quick Test Page completes printing, the Registration screen displays again.
Print tests
Input source tests
Input source print tests can verify that the printer can print on media from the installed input sources. Only
installed sources appear in the menu.
To run the input source test:
1. Select PRINT TESTS from Diagnostics Mode.
2. Select the input source from the sources displayed on the menu. All installed sources are listed.
3. Select either Single (feeds one sheet of blank media from the selected source) or Continuous (continues
feeding blank media from the selected source until Return or Stop is pressed) by using .
Press Return or Stop to exit the test.
Print quality pages (Prt Quality Pgs)
To print the Print Quality pages:
1. Select PRINT TESTS from Diagnostics Mode.
2. Select Prt Quality Pgs.
3. Press .
Four pages print. Additional button presses are ignored until the pages have printed.
The first page is a mix of graphics and text. The second two pages are graphics, and the last page is blank.
The Print Quality pages can also be printed from the Configuration Menu.
Menu selections Description
Tray 1 Standard tray
Tray 2* Optional tray
* If installed

Lexmark E352DN Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	2400 x 2400 DPI
Time to first page (black, normal)	6.5 s
Print speed (black, normal quality, A4/US Letter)	33 ppm
Internal memory	32 MB
Maximum internal memory	160 MB
Sound pressure level (printing)	52 dB
Total input capacity	250 sheets
Maximum input capacity	800 sheets
Envelopes sizes	7 3/4, 9, 10, B5, C5, DL
Maximum print size	210 x 297 mm
Media weight (tray 1)	80 gsm
Paper tray media types	Envelopes, Labels, Plain paper
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Statement (140 x 216mm), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
Maximum ISO A-series paper size	A4
Supported network protocols (IPv4)	TCP/IP IPv4, AppleTalk, TCP/IP IPv6
Compatible operating systems	Mac OS X Mac OS 9.x Citrix MetaFrame Linux Microsoft Windows 2000, NT, Me, XP, Server 2003, 98, Vista Novell UNIX
Maximum duty cycle	80000 pages per month
Sustainability certificates	ENERGY STAR
Operating altitude	0 - 2500 m
Operating temperature (T-T)	16 - 32 °C
Operating relative humidity (H-H)	8 - 80 %
Certification	FCC Class B, UL 60950-1, U.S. FDA, IEC 320-1, CSA, ICES Class B, CE Class B, CB IEC 60950-1, IEC 60825-1, GS (TÜV), SEMKO, UL AR, CS, TÜV Rh, N Mark, ACA C-tick Class B, CCC Class B, BSMI Class B, MIC, EK Mark, PSB

Weight and Dimensions

Dimensions (WxDxH)	396 x 359 x 259.5 mm
