Lexmark E352DN Service Manual

3-12 Lexmark™ E350d, E352dn
4512-420, -430
Printhead assembly mechanical adjustment
A printhead needs to be correctly positioned after it has been removed. Align it to the frame or use the same
position as the removed printhead. An indicator is located at the front right-hand screw for reference.
Note: Skew is caused by a sheet being fed through the printer while misaligned. The entire image is rotated
relative to the sheet edges. However, a mechanically misaligned printhead causes the horizontal lines to appear
skewed while the vertical lines remain parallel to the vertical edges.
There are no adjustments for skew. Check the pick roll (paper pick assembly) for wear, the paper path for
obstructions, the fuser for proper setting, and the tray paper guides for fit to the media.
To adjust the printhead:
1. Enter the Diagnostics Menu. See “Entering Diagnostics Mode” on page 3-5.
2. Select PRINT TESTS.
3. Select Tray 1.
4. Select Single.
5. Fold the printed test page on the left side so that a few millimeters of grid lines wrap around the outside of
the fold. See photo below.
6. Fold a second vertical fold near the center so that the left side top edge aligns with the right side top edge.
Printhead
misalignment
Paper feed
skew

Lexmark E352DN Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	2400 x 2400 DPI
Time to first page (black, normal)	6.5 s
Print speed (black, normal quality, A4/US Letter)	33 ppm
Internal memory	32 MB
Maximum internal memory	160 MB
Sound pressure level (printing)	52 dB
Total input capacity	250 sheets
Maximum input capacity	800 sheets
Envelopes sizes	7 3/4, 9, 10, B5, C5, DL
Maximum print size	210 x 297 mm
Media weight (tray 1)	80 gsm
Paper tray media types	Envelopes, Labels, Plain paper
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Statement (140 x 216mm), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
Maximum ISO A-series paper size	A4
Supported network protocols (IPv4)	TCP/IP IPv4, AppleTalk, TCP/IP IPv6
Compatible operating systems	Mac OS X Mac OS 9.x Citrix MetaFrame Linux Microsoft Windows 2000, NT, Me, XP, Server 2003, 98, Vista Novell UNIX
Maximum duty cycle	80000 pages per month
Sustainability certificates	ENERGY STAR
Operating altitude	0 - 2500 m
Operating temperature (T-T)	16 - 32 °C
Operating relative humidity (H-H)	8 - 80 %
Certification	FCC Class B, UL 60950-1, U.S. FDA, IEC 320-1, CSA, ICES Class B, CE Class B, CB IEC 60950-1, IEC 60825-1, GS (TÜV), SEMKO, UL AR, CS, TÜV Rh, N Mark, ACA C-tick Class B, CCC Class B, BSMI Class B, MIC, EK Mark, PSB

Weight and Dimensions

Dimensions (WxDxH)	396 x 359 x 259.5 mm
