Lexmark E352DN Service Manual

Diagnostic aids 3-3
4512-420, -430
Print quality pages (Prt Quality Pgs)
To print the Print Quality Pages:
1. Select Prt Quality Pgs from CONFIG MENU.
2. Press .
Four pages print. Additional button presses are ignored until the pages have printed. If duplex is selected,
the pages print front and back.
The first page is a mix of graphics and text. The second two pages are graphics, and the last page is blank.
The Print Quality Pages can also be printed from the Diagnostics Mode.
Panel Menus
If no password is set, Panel Menus lets you restrict access to the Ready Menu Group. When a password is set
by an administrator, this menu item does not appear.
1. Select Panel Menus from the CONFIG MENU.
2. Select Disable to make menus in the Ready Menu Group inaccessible.
To change the setting, select Panel Menus, and select Enable to make the menus available.
PPDS Emulation
This menu lets you turn on PPDS emulation, if desired.
1. Select PPDS Emulation from CONFIG MENU.
2. Select Activate to enable PPDS emulation and Deactivate to turn it off.
Demo Mode
This menu item lets you turn demo mode on or off.
1. Select Demo Mode from CONFIG MENU.
2. Select Activate to turn the demo mode on or Deactivate to turn demo mode off.
Factory Defaults
This menu lets you restore the printer settings to their factory default values.
1. Select Factory Defaults from the Configuration Menu.
2. Select either Restore Base or Restore Network. Restore Network is only available if an integrated
network adapter is installed.
Energy Conserve
Select On to allow access to the Power Saver menu. If you select Off, an additional item appears in the Power
Saver menu. Disable lets you enable or disable Power Saver from the customer menu.
Event Log
Selecting EVENT LOG provides a history of printer errors. The most recent error displays in position 1, and the
oldest error displays in position 10 (if 10 errors have occurred). If an error occurs after the log is full, the oldest
error is discarded. Identical errors in consecutive positions in the log are entered. All 2xx and 9xx error
messages are stored in the event log. See “Event log” on page 3-21 for more information.

Lexmark E352DN Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	2400 x 2400 DPI
Time to first page (black, normal)	6.5 s
Print speed (black, normal quality, A4/US Letter)	33 ppm
Internal memory	32 MB
Maximum internal memory	160 MB
Sound pressure level (printing)	52 dB
Total input capacity	250 sheets
Maximum input capacity	800 sheets
Envelopes sizes	7 3/4, 9, 10, B5, C5, DL
Maximum print size	210 x 297 mm
Media weight (tray 1)	80 gsm
Paper tray media types	Envelopes, Labels, Plain paper
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Statement (140 x 216mm), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
Maximum ISO A-series paper size	A4
Supported network protocols (IPv4)	TCP/IP IPv4, AppleTalk, TCP/IP IPv6
Compatible operating systems	Mac OS X Mac OS 9.x Citrix MetaFrame Linux Microsoft Windows 2000, NT, Me, XP, Server 2003, 98, Vista Novell UNIX
Maximum duty cycle	80000 pages per month
Sustainability certificates	ENERGY STAR
Operating altitude	0 - 2500 m
Operating temperature (T-T)	16 - 32 °C
Operating relative humidity (H-H)	8 - 80 %
Certification	FCC Class B, UL 60950-1, U.S. FDA, IEC 320-1, CSA, ICES Class B, CE Class B, CB IEC 60950-1, IEC 60825-1, GS (TÜV), SEMKO, UL AR, CS, TÜV Rh, N Mark, ACA C-tick Class B, CCC Class B, BSMI Class B, MIC, EK Mark, PSB

Weight and Dimensions

Dimensions (WxDxH)	396 x 359 x 259.5 mm
