Lexmark E352DN Service Manual

Diagnostic aids 3-5
4512-420, -430
Diagnostics mode
Entering Diagnostics Mode
1. Turn off the printer.
2. Press and hold Go and Back .
3. Turn on the printer.
4. Release the buttons when Performing Self Test displays.
Available tests
The tests display on the operator panel in the order shown:
Diagnostics mode tests
REGISTRATION
Margins
(top margin, bottom margin, left margin)
See “Margins” on page 3-7.
Quick Test See “Quick Test” on page 3-14.
Printhead See “Printhead assembly electronic adjustment” on page 3-8.
PRINT TESTS
Tray 1 See “Input source tests” on page 3-14.
Tray 2 (if installed) See “Input source tests” on page 3-14.
Prt Quality Pgs See “Print quality pages (Prt Quality Pgs)” on page 3-14.
HARDWARE TESTS
LCD Test See “LCD Test” on page 3-15.
Button Test See “Button Test” on page 3-15.
DRAM Test See “DRAM Test” on page 3-15.
DUPLEX TESTS
Quick Test See “Quick Test” on page 3-16.
Top margin See “Top Margin” on page 3-16.
Left Margin See “Left Margin” on page 3-16.
Sensor Test See “Sensor Test” on page 3-16.
Duplex Feed 1 See “Duplex Feed 1” on page 3-17.
INPUT TRAY TESTS
Feed Tests See “Feed Tests (input tray)” on page 3-17.
Sensor Test See “Sensor Test (input tray)” on page 3-18.
BASE SENSOR TEST
Front Door See “Front Door (front access door sensor)” on page 3-18.
Input See “Input (input sensor)” on page 3-18.
Output See “Output (exit sensor)” on page 3-18.
PRINTER SETUP
Defaults See “Defaults” on page 3-19.
Page Count See “Page Count” on page 3-19.
Perm Page Count See “Perm Page Count (permanent page count)” on page 3-19.
Serial Number See “Serial Number” on page 3-20.

Lexmark E352DN Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	2400 x 2400 DPI
Time to first page (black, normal)	6.5 s
Print speed (black, normal quality, A4/US Letter)	33 ppm
Internal memory	32 MB
Maximum internal memory	160 MB
Sound pressure level (printing)	52 dB
Total input capacity	250 sheets
Maximum input capacity	800 sheets
Envelopes sizes	7 3/4, 9, 10, B5, C5, DL
Maximum print size	210 x 297 mm
Media weight (tray 1)	80 gsm
Paper tray media types	Envelopes, Labels, Plain paper
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Statement (140 x 216mm), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
Maximum ISO A-series paper size	A4
Supported network protocols (IPv4)	TCP/IP IPv4, AppleTalk, TCP/IP IPv6
Compatible operating systems	Mac OS X Mac OS 9.x Citrix MetaFrame Linux Microsoft Windows 2000, NT, Me, XP, Server 2003, 98, Vista Novell UNIX
Maximum duty cycle	80000 pages per month
Sustainability certificates	ENERGY STAR
Operating altitude	0 - 2500 m
Operating temperature (T-T)	16 - 32 °C
Operating relative humidity (H-H)	8 - 80 %
Certification	FCC Class B, UL 60950-1, U.S. FDA, IEC 320-1, CSA, ICES Class B, CE Class B, CB IEC 60950-1, IEC 60825-1, GS (TÜV), SEMKO, UL AR, CS, TÜV Rh, N Mark, ACA C-tick Class B, CCC Class B, BSMI Class B, MIC, EK Mark, PSB

Weight and Dimensions

Dimensions (WxDxH)	396 x 359 x 259.5 mm
