Lexmark E360d - Page 122

4-34 Lexmark™ E360d, E360dn
4513-420, -430
6. Use a screwdriver to remove the e-clip (C) from the manual feed clutch.
Note: The picture below shows the E260d, E260dn printer. The manual feed clutch removal is the same for all
models.
7. Remove the manual feed clutch (D).
C
D
