3-6 Lexmark™ E360d, E360dn
4513-420, -430
Registration
The Registration menu settings adjust the black plane’s margins. To set print registration, select
REGISTRATION from the Diagnostics menu. The following will display:
Note: Pressing will display one margin setting per line below the REGISTRATION header.
The REGISTRATION settings and values are:
Margins
To change the value of any margin setting, press or to increase or decrease the margin setting value, and
then press to save. The panel displays Submitting changes... and returns to the initial REGISTRATION
menu screen. To exit the margin setting menu without changing the setting’s value, press .
Top Margin
This setting moves the black plane’s top margin up or down. Increasing the margin value moves text down the
page and increases the amount of space between the page’s top edge and the top margin. Decreasing the
margin value moves text up the page and narrows the amount of space between the page’s top edge and the
top margin. The default margin is 1/6 inch.
Note: Modifying the top margin moves the entire image either up or down on the physical page. In order to
preserve the bottom margin, changing the top margin does not compress or expand the image.
Bottom Margin
This setting moves the black plane’s bottom margin up or down. Increasing the margin value moves text down
the page and narrows the amount of space between the bottom edge of the page and the bottom margin.
Decreasing the margin value moves text up the page and widens the amount of space between the bottom edge
of the page and the bottom margin. The default margin is 1/6 inch.
Note: Modifying the bottom margin affects the rate of the stepper motor and may cause the page image to
be compressed or expanded.
Left Margin and Right Margin
These settings move the position of the black plane’s margin right or left. Increasing the margin value moves the
margin to the right. Decreasing the margin value moves the margin to the left. The default margin is 1/4 inch.
Note: Modifying the left and right margins moves the entire image left or right on the physical page. In
order to preserve the right margin, changing the left margin does not compress or expand the image.
REGISTRATION
Top Margin
Setting Value
Top Margin -16...16 (0)*
Bottom Margin -20...20 (0)*
Left Margin -25...25 (0)*
Right Margin -128...127 (0)*
Print Quick Test Page None
