Lexmark E360d User Manual

Diagnostic aids 3-3
4513-420, -430
Reset photoconductor maintenance counter (Reset PC Cnt)
The reset photoconductor maintenance counter resets the photoconductor kit page counter and clears any
warnings or photoconductor exhausted messages. This operation should be performed only after a new
photoconductor unit has been installed.
Print quality pages (Prt Quality Pgs)
The print quality test pages can be printed from either the Diagnostics menu or Configuration Menu (CONFIG
MENU). When printed from the Diagnostic mode, additional information is included, and the print cartridge
lockout is bypassed. See “Print quality pages (Prt Quality Pgs)” on page 3-3. Additional configuration
information may be included on the print quality pages which is not included on the print menu page.
To print the Print Quality Test Pages, select Prt Quality Pgs from CONFIG MENU. The message Printing
Quality Test Pages is displayed.
The print quality test consists of four pages. Page one contains device information, cartridge information, margin
settings, minimum stroke width, and a mixture of graphics and text. Page two is a gray page containing two
graphics, page three is black, and page four is blank. If the duplex is turned on, then the pages are duplexed.
The Print Quality Test pages are printed in English and must always be printed on letter, legal, or A4 paper.
Reports
The Reports menu contains two selections: Menu Settings Page and Event Log.
Menu Settings Page
The Menu Settings Page contains information...
To print the Menu Settings page, press . Press to return to the Configuration menu.
Event Log
The event log provides a history of printer errors. The event log can be printed only in the Configuration
menu. Additional options are available in the Diagnostics menu. See “Event log” on page 3-14.
To print the event log:
1. Select Print Event Log from the Event Log menu.
2. Press to return to the Configuration menu.
Note: An event log printed from the CONFIG MENU will not contain debug information or secondary
codes for 900 service errors. However, the event log printed from DIAGNOSTICS mode does include this
information.
Panel Menus
The settings are On and Off. The default is On.
PPDS Emulation
This menu item activates or deactivates PPDS emulation data stream. The selections are Deactivate (default)
and Activate. When PPDS emulation is activated, the following settings are also changed:
• SmartSwitch settings for each port are turned off.
• The printer language is changed to PPDS Emulation.
Users can still switch languages on the operator panel and through the PJL data stream.

Lexmark E360d Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Time to first page (black, normal)	6.5 s
Print speed (black, normal quality, A4/US Letter)	38 ppm
Duplex print speed (black, normal quality, A4/US Letter)	18 ppm
Processor frequency	400 MHz
Maximum internal memory	288 MB
Sound pressure level (printing)	53 dB
Total input capacity	300 sheets
Total output capacity	150 sheets
Maximum input capacity	850 sheets
Multi-Purpose tray input capacity	50 sheets
I/O ports	Centronics IEEE 1284 Bidirectional Parallel USB 2.0 Specification Hi-Speed Certified
Standard media sizes	10 Envelope 7 3/4 Envelope 9 Envelope A4 A5 B5 Envelope C5 Envelope DL Envelope A6 Card Executive Folio JIS-B5 Legal Letter Statement Universal Oficio
Compatible operating systems	Apple Mac OS X Apple Mac OS 9.x Microsoft Windows 2000 Server running Terminal Services with Citrix Presentation Server 3.0, 4.0 Microsoft Windows Server 2003 running Terminal Services with Citrix Presentation Server 3.0, 4.0, 4.5 Microsoft Windows Server 2003 x64 running Terminal Services with Citrix Presentation Server 4.0 x64, 4.5 x64 Linpus Linux Desktop 9.2, 9.3 Red Hat Enterprise Linux WS 3.0, 4.0, 5.0 SUSE Linux Enterprise Server 8.0, 9.0, 10.0 SUSE Linux Enterprise Desktop 10 openSUSE 10.2, 10.3, 11.0 Linspire Linux 6.0 Debian GNU/Linux 4.0 Red Flag Linux Desktop 5.0, 6.0 Ubuntu 7.10 Ubuntu 8.04 LTS Microsoft Windows 2000 Microsoft Windows XP Microsoft Windows Server 2003 Microsoft Windows XP x64 Microsoft Windows Server 2003 running Terminal Services Microsoft Windows 2000 Server running Terminal Services Microsoft Windows Server 2003 x64 Microsoft Windows Server 2003 x64 running Terminal Services Microsoft Windows Vista Microsoft Windows Vista x64 Microsoft Windows Server 2008 Microsoft Windows Server 2008 x64 Microsoft Windows Server 2008 running Terminal Services Microsoft Windows Server 2008 x64 running Terminal Services
Duty cycle letter size (maximum)	740 pages per month
Envelopes sizes	B5, C5, DL
Media types supported	Card Stock, Envelopes, Paper Labels, Plain Paper, Transparencies
Paper tray media types	Envelopes, Labels, Plain paper, Transparencies
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Statement (140 x 216mm), Legal (media size)
JIS B-series sizes (B0...B9)	B5
Maximum duty cycle	80000 pages per month
Certification	FCC Class B, UL 60950-1 3rd Edition, U.S. FDA, IEC 320-1, CSA, ICES Class B, Energy Star, CE Class B, CB IEC 60950-1, IEC 60825-1, GS (TÜV), SEMKO, UL AR, CS, TÜV Rh, N Mark, ACA C-tick Class B, CCC Class B, BSMI Class B, MIC, EK Mark, PSB

Weight and Dimensions

Dimensions (WxDxH)	406 x 370 x 260 mm
