Diagnostic aids 3-7
4513-420, -430
Quick Test page
Print a Quick Test page to verify that the REGISTRATION margin values are set appropriately. The Quick Test
page consists of the following:
• Alignment diamonds
• Horizontal lines used for skew adjustment
• General device information (current page count, installed memory, etc.)
• The printer’s serial number, code levels, and print registration settings
While the Quick Test page prints, Printing... will display. No buttons are active while the Quick Test page
prints. When the Quick Test page is finished printing, the display returns to the initial REGISTRATION menu
screen.
Note: Print the Quick Test page on Letter- or A4-sized media.
Print tests
This setting tests the printer’s ability to generate printed output from each of its installed input sources and to
test the printer’s current print quality.
Input sources
PRINT TESTS contains the following installed input sources:
• Tray1
• Manual Feeder
• MP Feeder
Press or to scroll through the PRINT TESTS menu, and then press to select the desired input source.
Single or Continuous is displayed on the screen. A Single test feeds one sheet of media from the selected input
and prints a test page on it. No buttons are active during the Single test. The Continuous test feeds media from
the selected input and prints test pages until is pressed. The printer always generates a simplexed
version of the Print Test page in its default resolution. While the Single or Continuous tests print, Printing...
will display. After the Single test prints or the Continuous test is canceled, the display returns to the PRINT
TESTS menu screen.
Note: The type of media installed in the selected input source will affect the contents of the page.
Print Quality Pages (Prt Quality Pgs)
This setting reports the values of a broad range of printer settings and tests the printer’s ability to generate
acceptable printed output. Press to print the report. Printing Quality Test Pages will display. Once started,
the printing cannot be canceled and no buttons are active until the printing completes.

Lexmark E360d Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Time to first page (black, normal)	6.5 s
Print speed (black, normal quality, A4/US Letter)	38 ppm
Duplex print speed (black, normal quality, A4/US Letter)	18 ppm
Processor frequency	400 MHz
Maximum internal memory	288 MB
Sound pressure level (printing)	53 dB
Total input capacity	300 sheets
Total output capacity	150 sheets
Maximum input capacity	850 sheets
Multi-Purpose tray input capacity	50 sheets
I/O ports	Centronics IEEE 1284 Bidirectional Parallel USB 2.0 Specification Hi-Speed Certified
Standard media sizes	10 Envelope 7 3/4 Envelope 9 Envelope A4 A5 B5 Envelope C5 Envelope DL Envelope A6 Card Executive Folio JIS-B5 Legal Letter Statement Universal Oficio
Compatible operating systems	Apple Mac OS X Apple Mac OS 9.x Microsoft Windows 2000 Server running Terminal Services with Citrix Presentation Server 3.0, 4.0 Microsoft Windows Server 2003 running Terminal Services with Citrix Presentation Server 3.0, 4.0, 4.5 Microsoft Windows Server 2003 x64 running Terminal Services with Citrix Presentation Server 4.0 x64, 4.5 x64 Linpus Linux Desktop 9.2, 9.3 Red Hat Enterprise Linux WS 3.0, 4.0, 5.0 SUSE Linux Enterprise Server 8.0, 9.0, 10.0 SUSE Linux Enterprise Desktop 10 openSUSE 10.2, 10.3, 11.0 Linspire Linux 6.0 Debian GNU/Linux 4.0 Red Flag Linux Desktop 5.0, 6.0 Ubuntu 7.10 Ubuntu 8.04 LTS Microsoft Windows 2000 Microsoft Windows XP Microsoft Windows Server 2003 Microsoft Windows XP x64 Microsoft Windows Server 2003 running Terminal Services Microsoft Windows 2000 Server running Terminal Services Microsoft Windows Server 2003 x64 Microsoft Windows Server 2003 x64 running Terminal Services Microsoft Windows Vista Microsoft Windows Vista x64 Microsoft Windows Server 2008 Microsoft Windows Server 2008 x64 Microsoft Windows Server 2008 running Terminal Services Microsoft Windows Server 2008 x64 running Terminal Services
Duty cycle letter size (maximum)	740 pages per month
Envelopes sizes	B5, C5, DL
Media types supported	Card Stock, Envelopes, Paper Labels, Plain Paper, Transparencies
Paper tray media types	Envelopes, Labels, Plain paper, Transparencies
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Statement (140 x 216mm), Legal (media size)
JIS B-series sizes (B0...B9)	B5
Maximum duty cycle	80000 pages per month
Certification	FCC Class B, UL 60950-1 3rd Edition, U.S. FDA, IEC 320-1, CSA, ICES Class B, Energy Star, CE Class B, CB IEC 60950-1, IEC 60825-1, GS (TÜV), SEMKO, UL AR, CS, TÜV Rh, N Mark, ACA C-tick Class B, CCC Class B, BSMI Class B, MIC, EK Mark, PSB

Weight and Dimensions

Dimensions (WxDxH)	406 x 370 x 260 mm
