Diagnostic aids 3-5
4513-420, -430
Diagnostics menu
Entering Diagnostics menu
1. Turn off the printer.
2. Press and hold and .
3. Turn on the printer.
4. Release the buttons when Performing Self Test displays.
Available tests
The menus display on the operator panel in the order shown:
Diagnostic menu settings
Note: Menus may vary depending on the features and options of the printer.
Registration See “Registration” on page 3-6.
Print tests See “Print tests” on page 3-7.
Hardware tests See “Hardware tests” on page 3-8.
Duplex tests (if installed) See “Duplex tests” on page 3-9.
Input tray tests See “Input tray tests” on page 3-10.
Output bin tests See “Output bin tests” on page 3-11.
Base sensor test See “Base sensor test (B. sensor test)” on page 3-11.
Printer setup See “Printer setup” on page 3-12.
EP setup See “EP setup” on page 3-13.
Event log See “Event log” on page 3-14.
Exit Diagnostics See “Exit Diagnostics” on page 3-15.
