Lexmark E360d - Cover Open Sensor

4-8 Lexmark™ E360d, E360dn
4513-420, -430
Cover open sensor
1. Remove the right side cover. See “Right side cover assembly removal” on page 4-61.
2. Disconnect the cable (A) from the controller board.
3. Use a #1 Phillips screwdriver to remove the screw (B) holding the sensor.
4. Remove the cover open sensor.
AB
