2-16 Lexmark™ E360d, E360dn
4513-420, -430
922.04 Hot roll timed out in trying to reach the final lamp
detection temperature.
Replace the fuser. See “Fuser service check”
on page 2-25.
922.05 Did not roll over to a steady state control in time after the
hot roll lamp detection.
922.06 Hot roll did not reach the operating temperature in time
(new enhanced control).
922.07 Media reached fuser nip, and fuser is under temperature
922.08 Fuser warm-up failure (motor start condition)
922.09 Fuser warm-up failure (compression set)
922.20 Belt fuser failed to reach the preheat temperature for the
motor to start during warm-up.
922.21 Belt fuser was under temperature when the media
reached the fuser nip.
923.00 Fuser is over temperature.
923.01 Fuser is over temperature. This applies to the fuser and
belt fusers.
924.00 Open thermistor check.
924.01 Open thermistor check failure. This applies to the fuser
and belt fusers.
924.02 Open thermistor check failure. The ADC failed to
converge. Possible noisy thermistor signal. This applies
to the fuser and belt fusers.
925.xx Wrong fuser installed. The fuser type stored in the
cartridge ID does not match the actual fuser installed in
the printer.
Fan service errors
927.00 Service fan error Replace the fan. See “Cooling fan service
check” on page 2-23.
927.03 Main fan took too long to ramp up
927.04 Main fan is under speed or stalled during speed
adjustment state
927.05 Main fan overspeed during speed adjustment state.
927.06 Main fan capture data is invalid, and speed control is at
maximum in fan control idle state
927.07 Main fan capture data is invalid, and speed control is at
maximum in fan control adjustment state.
Toner service errors
929.00 Toner sensor error Remove the toner cartridge, and shake it Try a
different toner cartridge, if possible. If the error
persists, then replace the toner level sensor. See
“Toner level sensor removal” on page 4-63.
929.01 No home window
929.02 No sensor transition (closed)
929.03 No sensor transition (open)
Printhead service errors
Error Description Action

Lexmark E360d Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Time to first page (black, normal)	6.5 s
Print speed (black, normal quality, A4/US Letter)	38 ppm
Duplex print speed (black, normal quality, A4/US Letter)	18 ppm
Processor frequency	400 MHz
Maximum internal memory	288 MB
Sound pressure level (printing)	53 dB
Total input capacity	300 sheets
Total output capacity	150 sheets
Maximum input capacity	850 sheets
Multi-Purpose tray input capacity	50 sheets
I/O ports	Centronics IEEE 1284 Bidirectional Parallel USB 2.0 Specification Hi-Speed Certified
Standard media sizes	10 Envelope 7 3/4 Envelope 9 Envelope A4 A5 B5 Envelope C5 Envelope DL Envelope A6 Card Executive Folio JIS-B5 Legal Letter Statement Universal Oficio
Compatible operating systems	Apple Mac OS X Apple Mac OS 9.x Microsoft Windows 2000 Server running Terminal Services with Citrix Presentation Server 3.0, 4.0 Microsoft Windows Server 2003 running Terminal Services with Citrix Presentation Server 3.0, 4.0, 4.5 Microsoft Windows Server 2003 x64 running Terminal Services with Citrix Presentation Server 4.0 x64, 4.5 x64 Linpus Linux Desktop 9.2, 9.3 Red Hat Enterprise Linux WS 3.0, 4.0, 5.0 SUSE Linux Enterprise Server 8.0, 9.0, 10.0 SUSE Linux Enterprise Desktop 10 openSUSE 10.2, 10.3, 11.0 Linspire Linux 6.0 Debian GNU/Linux 4.0 Red Flag Linux Desktop 5.0, 6.0 Ubuntu 7.10 Ubuntu 8.04 LTS Microsoft Windows 2000 Microsoft Windows XP Microsoft Windows Server 2003 Microsoft Windows XP x64 Microsoft Windows Server 2003 running Terminal Services Microsoft Windows 2000 Server running Terminal Services Microsoft Windows Server 2003 x64 Microsoft Windows Server 2003 x64 running Terminal Services Microsoft Windows Vista Microsoft Windows Vista x64 Microsoft Windows Server 2008 Microsoft Windows Server 2008 x64 Microsoft Windows Server 2008 running Terminal Services Microsoft Windows Server 2008 x64 running Terminal Services
Duty cycle letter size (maximum)	740 pages per month
Envelopes sizes	B5, C5, DL
Media types supported	Card Stock, Envelopes, Paper Labels, Plain Paper, Transparencies
Paper tray media types	Envelopes, Labels, Plain paper, Transparencies
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Statement (140 x 216mm), Legal (media size)
JIS B-series sizes (B0...B9)	B5
Maximum duty cycle	80000 pages per month
Certification	FCC Class B, UL 60950-1 3rd Edition, U.S. FDA, IEC 320-1, CSA, ICES Class B, Energy Star, CE Class B, CB IEC 60950-1, IEC 60825-1, GS (TÜV), SEMKO, UL AR, CS, TÜV Rh, N Mark, ACA C-tick Class B, CCC Class B, BSMI Class B, MIC, EK Mark, PSB

Weight and Dimensions

Dimensions (WxDxH)	406 x 370 x 260 mm
