Lexmark MS517dn User Manual

Error code Description Action
32.34 Unsupported cartridge Go to
“Unsupported toner cartridge service
check” on page 126.
32.35 Unsupported imaging unit Go to
“Unsupported imaging unit service check”
on page 127.
32.37 Unsupported cartridge Go to
“Unsupported toner cartridge service
check” on page 126.
32.38 Unsupported imaging unit Go to
“Unsupported imaging unit service check”
on page 127.
33.01 Unsupported cartridge Go to
“Unsupported toner cartridge service
check” on page 126.
33.02 Unsupported imaging unit Go to
“Unsupported imaging unit service check”
on page 127.
34 Media size mismatch (too short or too narrow) Go to
“Media size mismatch service check” on
page 129.
35 Res save o deficient memory Go to
“Insucient memory service check” on
page 131.
37 Insucient collation area Go to
“Insucient memory service check” on
page 131.
38 Memory full Go to
“Insucient memory service check” on
page 131.
41.01 Imaging unit/cartridge mismatch Go to
“Supplies mismatch service check” on
page 130.
41.10 Cartridge/imaging unit mismatch Go to
“Supplies mismatch service check” on
page 130.
42 Printer/cartridge region mismatch Go to
“Printer/cartridge mismatch service
check” on page 127.
52 Flash full Go to
“Flash full service check” on page 131.
54 Network error Go to
“Network service check” on page 169.
61 The hard disk is defective Go to
“Hard disk failure service check” on
page 133
62 The hard disk is full
80 Maintenance kit Go to
“Maintenance kit service check” on
page 132.
84 Imaging unit low Go to
“Imaging unit low service check” on
page 132.
88 Toner cartridge low Go to
“Toner cartridge low service check” on
page 132.
4514-6xx
Diagnostics and troubleshooting
125

Lexmark MS517dn Specifications

General

Cables included	AC
Cartridge(s) included	Yes
Included cartridge capacity (black)	3000 pages
Color	No
Print technology	Laser
Time to first page (black, normal)	6.5 s
Print speed (black, normal quality, A4/US Letter)	42 ppm
Duplex print speed (black, normal quality, A4/US Letter)	18 ppm
Processor cores	2
Noise level (idle)	15 dB
Processor frequency	800 MHz
Maximum internal memory	1280 MB
Sound pressure level (printing)	55 dB
Sound pressure level (duplex printing)	54 dB
Envelopes sizes	7 3/4, 9, 10, DL
Paper tray media types	Card stock, Envelopes, Labels, Plain paper, Transparencies
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm), Universal, Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Total input capacity	350 sheets
Total output capacity	150 sheets
Maximum input capacity	2000 sheets
Maximum number of input trays	5
Multi-Purpose tray input capacity	100 sheets
USB connector	USB Type-B
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
USB 2.0 ports quantity	1
Wi-Fi	-
Cabling technology	10/100/1000Base-T(X)
Security algorithms	LEAP, MD5, MSCHAPv2, PEAP, SNMPv3, SSL/TLS, TTLS
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Supported network protocols (IPv4)	TCP/IP IPv4, AppleTalk
Supported network protocols (IPv6)	TCP/IP IPv6, TCP, UDP
Package depth	472 mm
Package width	432 mm
Package height	380 mm
Package weight	16700 g
Power consumption (off)	0.5 W
Power consumption (ready)	7 W
Power consumption (printing)	600 W
Energy Star Typical Electricity Consumption (TEC)	2.1 kWh/week
Display	LCD
Certification	ENERGY STAR, Blue Angel RAL-UZ-171, ICES-003 Class B, BSMI Class B, VCCI Class B, US FDA, UL 60950-1, FCC Class B, cUL CAN/CSA-C22.2 60950-1, NOM, CB EN/IEC 60950-1, CB EN/IEC 60825-1, CE DoC (EN 62301 Class B, EN 62311, CE EN/IEC 60950-1, CE EN/IEC 60825-1, EN 61000-3, EN 55022 Class B, EuP, EN 55024, UL), EFTA (CE), KCC, CCC, CECP, CEL, C-tick DoC, UL-AR, KC mark, UL GS mark, EC 1275, MET-I, ISO 532B, ECMA-370, TED, GOST-R, SII, TER
Product color	Gray
Display diagonal	2.4 \
Printing colors	Black
Country of origin	China
Maximum duty cycle	120000 pages per month
Recommended duty cycle	1500 - 14000 pages per month
Page description languages	Microsoft XPS, PCL 5e, PCL 6, PDF 1.7, PPDS, PostScript 3
Sustainability certificates	Blue Angel, ENERGY STAR
Operating altitude	0 - 2896 m
Operating temperature (T-T)	16 - 32 °C
Operating relative humidity (H-H)	8 - 80 %
Authentication method	802.1x

Weight and Dimensions

Depth	382 mm
Width	399 mm
Height	263 mm
