Lexmark MS517dn User Manual

23y paper jams
23y paper jam messages
Error code Description Action
230.01 Sheet covering internal duplex sensor during
warm up.
Go to
“Duplex service check” on page 98.
230.02 Paper jam around internal duplex. Go to
“Duplex service check” on page 98.
230.03 Internal duplex sensor never made by leading
edge of page.
Go to
“Duplex service check” on page 98.
230.04 Page in duplexer ahead of current reversing page
never staged.
Go to
“Duplex service check” on page 98.
230.05 Internal duplex sensor never broke on the trailing
edge of the sheet.
Go to
“Duplex service check” on page 98.
230.07 Internal duplex sensor never broke from sheet
ahead of page.
Go to
“Duplex service check” on page 98.
230.09 Page in duplexer never picked. Go to
“Duplex service check” on page 98.
230.10 Narrow page reversing into duplexer. Go to
“Duplex service check” on page 98.
230.28 Bouncy duplex sensor never made. Go to
“Duplex service check” on page 98.
232.03 Input sensor never detected sheet from internal
duplex path.
Go to
“Duplex service check” on page 98.
232.10 Feed error picking from the duplexer. Go to
“Duplex service check” on page 98.
Duplex service check
Action Yes No
Step 1
a Remove the rear cover. See “Rear door and cover removal”
on page 307.
b Check the redrive rollers for wear or damage.
Are they free of wear or damage?
Go to step 2. Replace the redrive
assembly. See
“Redrive assembly
removal” on
page 310.
Step 2
a Remove the left cover. See “Left cover removal” on page
228.
b POR into the Diagnostics menu and perform a duplex feed test:
Diagnostics Menu > Duplex Tests > Duplex Feed 1
c Check the reverse solenoid for proper operation.
Does it function properly?
Go to step 3. Replace the reverse
solenoid. See
“Reverse solenoid
removal” on
page 237.
4514-6xx
Diagnostics and troubleshooting
98

Lexmark MS517dn Specifications

General

Cables included	AC
Cartridge(s) included	Yes
Included cartridge capacity (black)	3000 pages
Color	No
Print technology	Laser
Time to first page (black, normal)	6.5 s
Print speed (black, normal quality, A4/US Letter)	42 ppm
Duplex print speed (black, normal quality, A4/US Letter)	18 ppm
Processor cores	2
Noise level (idle)	15 dB
Processor frequency	800 MHz
Maximum internal memory	1280 MB
Sound pressure level (printing)	55 dB
Sound pressure level (duplex printing)	54 dB
Envelopes sizes	7 3/4, 9, 10, DL
Paper tray media types	Card stock, Envelopes, Labels, Plain paper, Transparencies
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm), Universal, Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Total input capacity	350 sheets
Total output capacity	150 sheets
Maximum input capacity	2000 sheets
Maximum number of input trays	5
Multi-Purpose tray input capacity	100 sheets
USB connector	USB Type-B
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
USB 2.0 ports quantity	1
Wi-Fi	-
Cabling technology	10/100/1000Base-T(X)
Security algorithms	LEAP, MD5, MSCHAPv2, PEAP, SNMPv3, SSL/TLS, TTLS
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Supported network protocols (IPv4)	TCP/IP IPv4, AppleTalk
Supported network protocols (IPv6)	TCP/IP IPv6, TCP, UDP
Package depth	472 mm
Package width	432 mm
Package height	380 mm
Package weight	16700 g
Power consumption (off)	0.5 W
Power consumption (ready)	7 W
Power consumption (printing)	600 W
Energy Star Typical Electricity Consumption (TEC)	2.1 kWh/week
Display	LCD
Certification	ENERGY STAR, Blue Angel RAL-UZ-171, ICES-003 Class B, BSMI Class B, VCCI Class B, US FDA, UL 60950-1, FCC Class B, cUL CAN/CSA-C22.2 60950-1, NOM, CB EN/IEC 60950-1, CB EN/IEC 60825-1, CE DoC (EN 62301 Class B, EN 62311, CE EN/IEC 60950-1, CE EN/IEC 60825-1, EN 61000-3, EN 55022 Class B, EuP, EN 55024, UL), EFTA (CE), KCC, CCC, CECP, CEL, C-tick DoC, UL-AR, KC mark, UL GS mark, EC 1275, MET-I, ISO 532B, ECMA-370, TED, GOST-R, SII, TER
Product color	Gray
Display diagonal	2.4 \
Printing colors	Black
Country of origin	China
Maximum duty cycle	120000 pages per month
Recommended duty cycle	1500 - 14000 pages per month
Page description languages	Microsoft XPS, PCL 5e, PCL 6, PDF 1.7, PPDS, PostScript 3
Sustainability certificates	Blue Angel, ENERGY STAR
Operating altitude	0 - 2896 m
Operating temperature (T-T)	16 - 32 °C
Operating relative humidity (H-H)	8 - 80 %
Authentication method	802.1x

Weight and Dimensions

Depth	382 mm
Width	399 mm
Height	263 mm
